INDOOR LINEAR PROFILES
BRENTA 1
BRENTA 2
WCBR17FC
2247 mm
WCBR19FC
2807 mm
h 80 mm
WCBR27FC
2247 mm
WCBR29FC
2807 mm
h 76 mm
WCBR17AC
2247 mm
WCBR19AC
2807 mm
h 95 mm
WCBR27AC
2247 mm
WCBR29AC
2807 mm
h 91 mm
1. OUTER CASING
3. SCREEN
2. LIGHTING
FIXTURE
CODE
DALI 27W/m
BR1 111 0BD
ON/OFF
BR1 1 1 0B0
LENGTH
1 - 562 mm
2 - 842 mm
3 - 1122 mm
5 - 1682 mm
7 - 2242 mm
9 - 2802 mm
POWER
0 - 19W/m
1 - 27W/m
LED COLOUR
F - 2700K
5 - 3000K
9 - 4000K
CODE
DALI 54W/m
BR2 111 0BD
ON/OFF
BR2 1 1 0B0
LENGTH
1 - 562 mm
2 - 842 mm
3 - 1122 mm
5 - 1682 mm
7 - 2242 mm
9 - 2802 mm
POWER
0 - 27W/m
1 - 54W/m
LED COLOUR
F - 2700K
5 - 3000K
9 - 4000K
Diffuse optics
Microprismatic optics
Outer casing
for flush installation
see the standard outer casings
on p. 687 and 689 to achieve
the desired length, if necessary
Outer casing
for deep-set installation – black
see the standard outer casings
on p. 687 and 689 to achieve
the desired length, if necessary
Required outer casing, not included
Required screen, not included
WRBR105D
5000 mm
WRBR110D
10000 mm
WRBR115D
15000 mm
WRBR205D
5000 mm
WRBR210D
10000 mm
WRBR215D
15000 mm
WRBR105P
5000 mm
WRBR110P
10000 mm
WRBR115P
15000 mm
WRBR205P
5000 mm
WRBR210P
10000 mm
WRBR215P
15000 mm
