L&L Luce&Light
652
50
81
50
BITPOP C 1.0
IP40
POWER / POWER SUPPLY
CODE
6.5W 24Vdc
BC1000 B 0
BC1000 N 0
White - Black
Black - Black
LED COLOUR
1F - 2700K CRI >90
15 - 3000K CRI >90
09 - 4000K CRI 80
OPTICS
S - 17°
F - 30°
L - 42°
W - 17°x45°
CONTROL SYSTEM
LUMEN OUTPUT AT SOURCE
480 lm (3000K)
DELIVERED LUMEN OUTPUT
335 lm (3000K, 30°)
NO. AND TYPE OF LED
1 high-intensity power LED
3-step MacAdam, 50000h L85 B10 (Ta 25°C)
MATERIAL
body in aluminium
trim in steel
POWER SUPPLY UNIT
not included, see p. 904
POWER CABLES
includes 1.5 m PVC cable
FROR 2x0.35 Ø3.5 mm
MOUNTING
surface mounted (ceiling)
FEATURES
UGR < 10 for the 17° and 30° optics
NOTES
recessed version: Bitpop 1.0, p. 532
Casambi-compatible version, controllable with
the Casambi app, available on request
PHOTOMETRIC DATA
see p. 793
Interior: black
Finish: white, black
BITPOP C 1.0
4000K, 6.5W, 17°, black
Project by / Studio Carella + Salvato
Executed by / ing. Giuseppe Occulto
Photo by / Alessio Tamborini
LEX law firm, Foggia, Italy
kg 0.30
