L&L Luce&Light
425
99
143
44
99
46
143
230Vac
230Vac
85x125 mm
PASITO MINI
24Vdc
24Vdc
IK06
IK06
IP65
IP65
PASITO MINI 1.1
PASITO MINI 1.2
OUTDOOR STEP LIGHTS
6W 230Vac
PM1110 E
PM1110 F
PM1110 H
PM1110 T
White
Grey
Anthracite
Cor-ten
5W 24Vdc
PM1100 E
PM1100 F
PM1100 H
PM1100 T
White
Grey
Anthracite
Cor-ten
0 - CRI 80
1 - CRI >90
F - 2700K
5 - 3000K
9 - 4000K
A - asymmetrical, 150°x90°
B - 60°
383 lm (3000K, CRI 80)
214 lm (3000K, 150°x90°, CRI 80,
white finish)
1 high-intensity power LED
1/4 ANSI BIN, 50000h L90 B10 (Ta 25°C)
body in technopolymer and aluminium
230Vac: included
24Vdc: not included, see p. 904
230Vac: includes 0.20 m neoprene cable
H05RN-F 2x1.00 Ø7.0 mm
24Vdc: includes 0.30 m neoprene cable
H05RN-F 2x0.35/0.75 Ø6.3 mm
recessed, with frame (wall)
see p. 429
see p. 858
6W 230Vac
PM1210 E
PM1210 F
PM1210 H
PM1210 T
White
Grey
Anthracite
Cor-ten
5W 24Vdc
PM1200 E
PM1200 F
PM1200 H
PM1200 T
White
Grey
Anthracite
Cor-ten
0 - CRI 80
1 - CRI >90
F - 2700K
5 - 3000K
9 - 4000K
A - asymmetrical, 150°x90°
B - 60°
383 lm (3000K, CRI 80)
214 lm (3000K, 150°x90°, CRI 80,
white finish)
1 high-intensity power LED
1/4 ANSI BIN, 50000h L90 B10 (Ta 25°C)
body in technopolymer and aluminium
230Vac: included
24Vdc: not included, see p. 904
230Vac: includes 0.20 m neoprene cable
H05RN-F 2x1.00 Ø7.0 mm
24Vdc: includes 0.30 m neoprene cable
H05RN-F 2x0.35/0.75 Ø6.3 mm
surface mounted (wall)
none
see p. 858
kg 0.30
kg 0.40
Power supply unit included in
the 230Vac version
Power supply unit included in
the 230Vac version
White
Anthracite
Grey
Cor-ten
