L&L Luce&Light
256
DUOMO 2.0
DUOMO 1.0
IK06
IK06
IP54
IP54
156
166
50
260
24
68
220°
86
24
68
166
50
260
220°
kg 0.80
kg 1.55
POWER / POWER SUPPLY
CODE
10W 230Vac ON/OFF
DU1010 00 0 6
DU1010 00 0 E
DU1010 00 0 H
Antique white
White
Anthracite
CRI
0 - CRI 80
1 - CRI >90
HONEYCOMB LOUVRE
0 - not present
1 - present
(not compatible with the 10° optics)
LED COLOUR
F - 2700K
5 - 3000K
9 - 4000K
OPTICS
T - 10°
S - 14°
M - 30°
L - 35°
J - 43°
K - 63°
W- 18°x44°
X - 44°x18°
LUMEN OUTPUT AT SOURCE
880 lm (3000K, CRI 80)
DELIVERED LUMEN OUTPUT
714 lm (3000K, 30°, CRI 80)
NO. AND TYPE OF LED
2 high-intensity power LEDs
3-step MacAdam, 50000h L90 B10 (Ta 25°C)
MATERIAL
body and bracket in Anticorodal aluminium
screen in serigraphed, tempered, extra-clear glass
POWER SUPPLY UNIT
built in
MOUNTING
surface mounted (ceiling, wall, floor)
ACCESSORIES
see p. 259
FEATURES
fast installation: direct connection between fixture
and mains power supply
NOTES
available on request with adapter for Eurostandard
track and in DALI, 0/1–10V or PUSH version,
or with Bluetooth control
Casambi-compatible version, controllable with
the Casambi app, available on request
PHOTOMETRIC DATA
see p. 821
19W 230Vac ON/OFF
DU2010 00 0 6
DU2010 00 0 E
DU2010 00 0 H
Antique white
White
Anthracite
0 - CRI 80
1 - CRI >90
0 - not present
1 - present
(not compatible with the 10° optics)
F - 2700K
5 - 3000K
9 - 4000K
T - 10°
S - 14°
M - 30°
L - 35°
J - 43°
K - 63°
W- 18°x44°
X - 44°x18°
1760 lm (3000K, CRI 80)
1428 lm (3000K, 30°, CRI 80)
4 high-intensity power LEDs
3-step MacAdam, 50000h L90 B10 (Ta 25°C)
body and bracket in Anticorodal aluminium
screen in serigraphed, tempered, extra-clear glass
built in
surface mounted (ceiling, wall, floor)
see p. 259
fast installation: direct connection between fixture
and mains power supply
available on request with adapter for Eurostandard
track and in DALI, 0/1–10V or PUSH version,
or with Bluetooth control
Casambi-compatible version, controllable with
the Casambi app, available on request
see p. 821 and 822
18°x44° optics
44°x18° optics
