L&L Luce&Light
217
1510
37
56
47
2010
37
56
47
RIO 2.3
RIO 2.4
IK10
IK10
IP67
IP67
RIO 2
OUTDOOR LINEAR PROFILES
29W 24Vdc white light 1510 mm
26W 24Vdc RGB light 1510 mm
RE2300 D B -
F - 2600K
5 - 2800K
9 - 3700K
6 - RGB
includes 1.5 m neoprene cable
H05RN-F 2x0.35/0.75 Ø6.3 mm
RGB: includes 1.5 m FEP+PCP cable
(equivalent to H05RN-F) 4x0.50/0.50 Ø6.3 mm
1 - 5 m
2 - 10 m (only white light)
3 - 15 m (only white light)
4 - 20 m (only white light)
diffuse
3168 lm (2800K)
RGB: 420 lm, R: 90 lm G: 270 lm B: 60 lm
870 lm (2800K)
RGB: 300 lm, R: 66 lm G: 192 lm B: 42 lm
288 low-power SMD LEDs
3-step MacAdam
RGB: full-colour SMD LEDs
50000h L95 B10 (Ta 25°C)
body in PMMA
screen in opal PMMA
end caps in AISI 316L stainless steel
not included, see p. 904 and 917
recessed (ceiling, wall, ground)
see p. 219
underwater version: Rio Sub 2, p. 773
non-standard lengths available on request
see p. 870
38W 24Vdc white light 2010 mm
34W 24Vdc RGB light 2010 mm
RE2400 D B -
F - 2600K
5 - 2800K
9 - 3700K
6 - RGB
includes 1.5 m neoprene cable
H05RN-F 2x0.35/0.75 Ø6.3 mm
RGB: includes 1.5 m FEP+PCP cable
(equivalent to H05RN-F) 4x0.50/0.50 Ø6.3 mm
1 - 5 m
2 - 10 m (only white light)
3 - 15 m (only white light)
4 - 20 m (only white light)
diffuse
4224 lm (2800K)
RGB: 560 lm, R: 120 lm G: 360 lm B: 80 lm
1160 lm (2800K)
RGB: 400 lm, R: 88 lm G: 256 lm B: 56 lm
384 low-power SMD LEDs
3-step MacAdam
RGB: full-colour SMD LEDs
50000h L95 B10 (Ta 25°C)
body in PMMA
screen in opal PMMA
end caps in AISI 316L stainless steel
not included, see p. 904 and 917
recessed (ceiling, wall, ground)
see p. 219
underwater version: Rio Sub 2, p. 773
non-standard lengths available on request
see p. 870
kg 2.34
kg 2.66
kg 5000 / kN 50
with aluminium
outer casing
kg 5000 / kN 50
with aluminium
outer casing
