L&L Luce&Light
216
1010
37
56
47
RIO 2.2
IK10
IP67
POWER / POWER SUPPLY
CODE
19W 24Vdc white light 1010 mm
17W 24Vdc RGB light 1010 mm
RE2200 D B -
LED COLOUR
F - 2600K
5 - 2800K
9 - 3700K
6 - RGB
POWER CABLES
includes 1.5 m neoprene cable
H05RN-F 2x0.35/0.75 Ø6.3 mm
RGB: includes 1.5 m FEP+PCP cable
(equivalent to H05RN-F) 4x0.50/0.50 Ø6.3 mm
1 - 5 m
2 - 10 m (only white light)
3 - 15 m (only white light)
4 - 20 m (only white light)
OPTICS
diffuse
LUMEN OUTPUT AT SOURCE
2112 lm (2800K)
RGB: 280 lm, R: 60 lm G: 180 lm B: 40 lm
DELIVERED LUMEN OUTPUT
580 lm (2800K)
RGB: 200 lm, R: 44 lm G: 128 lm B: 28 lm
NO. AND TYPE OF LED
192 low-power SMD LEDs
3-step MacAdam
RGB: full-colour SMD LEDs
50000h L95 B10 (Ta 25°C)
MATERIAL
body in PMMA
screen in opal PMMA
end caps in AISI 316L stainless steel
POWER SUPPLY UNIT
not included, see p. 904 and 917
MOUNTING
recessed (ceiling, wall, ground)
ACCESSORIES
see p. 219
NOTES
underwater version: Rio Sub 2, p. 773
non-standard lengths available on request
PHOTOMETRIC DATA
see p. 870
kg 1.48
kg 5000 / kN 50
with aluminium
outer casing
