kreon inti
103
Ø80
103
Ø95
103
Ø80
103
Ø95
inti fixed with trimless plasterkit
inti fixed with trim
inti directional with trimless plasterkit
inti directional with trim
↑ back to kreon inti
catalogue 4
CRI
CCT
Wattage
Drive current
Fixture lumen
1
LED dome
LED dir.
33° / 56°
20°
CRI90+
2700K/3000K
12W
4W
1W
350mA
576lm
250lm
100lm
➁
LED dome
LED dir.
33° / 56°
20°
CRI90+
2700K/3000K
12,6W
4W
1W
350mA
400lm
250lm
100lm
Colour
KR-code
Light sources
9027
2700K, CRI90+
9030
3000K, CRI90+
SP
spot (20°)
DL
dark light (33°)
WDL
wide dark light (56°)
D1
dome, glassy
D3
dome, matt
Required accessories
Optional accessories
inti 80 fixed
Gear: excl., IP44 4
○
KR997111
➀
●
●
●
●
■
■
●
KR997112
➀
●
●
●
●
■
■
inti 80 fixed dim-to-warm (3000K to 1800K)
Gear: excl., IP44 4
○
KR997611
➁
●
●
■
■
●
KR997612
➁
●
●
■
■
inti 80 directional
Gear: excl., IP40 4
○
KR997121
➂
●
●
●
●
●
●
●
■
■
●
KR997122
➂
●
●
●
●
●
●
●
■
■
inti 80 directional dim-to-warm (3000K to 1800K)
Gear: excl., IP40 4
○
KR997621
➃
●
●
●
●
●
●
●
■
■
●
KR997622
➃
●
●
●
●
●
●
●
■
■
REMARKS
➊ Tool is for use with kreon inti 80
fixed. To be used in maintenance.
One per project is recommended.
➋ The dome and directional spot
need to be driven separately.
➌ Driver suitable for directional
spot and dome combined.
Removal tool
■ Required accessories
Plasterkit
KR717104
Plasterkit, front mounting, no shadowgap, trimless finishing 1 Ø 102 D 110
KR717108
Plasterkit, front mounting, shadowgap, trimless finishing 1 Ø 102 D 110
KR717000
Plasterkit, back mounting, no shadowgap
Installation kit
○
KR717021
Installation kit with trim, white 1 Ø 90 D 110
●
KR717022
Installation kit with trim, black 1 Ø 90 D 110
Plasterkit concrete
KR717101
Plasterkit for concrete installation, no shadowgap (430x430)
KR717102
Plasterkit for concrete installation, no shadowgap, small (200x200)
KR717109
Plasterkit for concrete installation, shadowgap (430x430)
KR717107
Plasterkit for concrete installation, shadowgap, small (200x200)
Installation kit for wooden ceiling
KR717100
Installation kit, no shadowgap
■ Optional accessories
Driver
KR747064
LED driver, 350mA, 19W, ON/OFF ➋
KR739102
LED driver, 350mA, 15W, 0/1-10V
KR747266
LED driver, 350mA, 15W, DALI ➋
KR747163
LED driver, 350mA, 18W, 0-10V/1-10V, dim-to-warm ➋
KR747267
LED driver, 350mA, 17W, DALI, dim-to-warm
KR747966
LED dual driver, 2x 350mA, 20W, DALI ➌
KR772219
LED driver, 350mA, 18,5W, Casambi
Distance ring (for plasterkit concrete)
KR717307
Distance ring 2mm (set of 5 pcs.)
KR717308
Distance ring 3mm (set of 5 pcs.)
KR717309
Distance ring 5mm (set of 5 pcs.)
Removal tool
KR797001
Removal tool for kreon inti fixed ➊
See page 690 for more information
about different installation kits.
Thickness boardmaterial: 9-26mm
Gear excluded
IP40 (fixed) - IP44 (directional)
