TABULA _TECHNICAL SPECIFICATIONS
TABULA _TECHNICAL SPECIFICATIONS
ACCESSORIES
FRONT SCREENS – TO BE USED WITH FIXED and HEIGHT-ADJUSTABLE DESKS - and WITH FIXED HEIGHT BENCH
Available in the following materials:
- FABRIC (colours: Orange Melange, Green, Sky Blue and Sand, with variable density sound-absorbent mat obtained by thermoforming the material with
aluminium mould. This technique makes it possible to obtain and item that can absorb a larger spectrum of wavelengths.
Available in Semi-circle (L.76 x H.39 cm) and Rectangle (77, 117, 137 and 157 x H.39 cm) configurations.
- LAMINATE made from 18 mm-thick particleboard, with a density of about 650 kg/m³, covered on both sides by a layer of melamine-coated paper
(120 g/m²), with a scratch-proof and anti-reflective surface, in the following finishes: Ivory, Cement Render Effect, Dark Brown Elm, Cream Elm, Black
Walnut, Vulcano, Graphite, Warm Grey, Moss Grey and Petrol Green.
The panels have high bending and tensile strength, and excellent resistance to ageing and stains.
The edges are made from an ABS compound, fixed with polyurethane glue and rounded.
The standard panels used are classified for reaction to fire in Class 2.
Available in the RECTANGLE configuration
- GLASS made from 8-mm thick etched and tempered float glass. Available in the RECTANGLE configuration
All the screens are coupled to the structure by means of two brackets made from Nylon 6 + 20% GF (colours: White or Anthracite), complete with two
clips made from Nylon 6 + 20% GF (colours: White or Anthracite).
SIDE SCREEN available in the following materials:
- FABRIC (colours: Orange Melange, Green, Sky Blue and Sand, with variable density sound-absorbent mat obtained by thermoforming the material
with aluminium mould. This technique makes it possible to obtain and item that can absorb a larger spectrum of wavelengths. Available in the SHAPED
configuration (L.73 x H.39 cm)
- LAMINATE made from 18 mm-thick particleboard, with a density of about 650 kg/m³, covered on both sides by a layer of melamine-coated paper (120
g/m²), with a scratch-proof and anti-reflective surface, in the following finishes: Ivory, Cement Render Effect, Dark Brown Elm, Cream Elm, Black Walnut,
Vulcano, Graphite, Warm Grey, Moss Grey and Petrol Green.
The panels have high bending and tensile strength, and excellent resistance to ageing and stains.
The edges are made from an ABS compound, fixed with polyurethane glue and rounded.
The standard panels used are classified for reaction to fire in Class 2.
Available in the SHAPED configuration (L.73 x H.39 cm)
The side screens can be attached to the top using a kit composed of a holding bracket and a metal clip (available colours: Ral 9016 matte White and
Anthracite Mica) orby resting it on the top by means of a metal plate (available colours: Ral 9016 matte White and Anthracite Mica).
The second option means the side screen can be freely positioned.
FRONT SCREENS – TO BE USED with HEIGHT-ADJUSTABLE BENCH ONLY (ONE-CLICK AND ELECTRIC)
Available in the following materials:
- FABRIC (colours: Orange Melange, Green, Sky Blue and Sand (inner mat with square pattern stitching).
These are available in Rectangular configuration in sizes L.128, 148,168 and 188 x H.105 cm.
Bearing structure composed of two vertical uprights in round tubular steel (diameter 35xD.2 mm) and by a horizontal crosspiece in square tubular steel
(30x30xD.2 mm) with epoxy powder-coated finishes of Ral 9016 matte White and Anthracite Mica.
The structure comes with caps made from moulded ABS (colours: White or Anthracite).
- LAMINATE made from 18 mm-thick particleboard, with a density of about 650 kg/m³, covered on both sides by a layer of melamine-coated paper
(120 g/m²), with a scratch-proof and anti-reflective surface, in the following finishes: Ivory, Cement Render Effect, Dark Brown Elm, Cream Elm, Black
Walnut, Vulcano, Graphite, Warm Grey, Moss Grey and Petrol Green.
The panels have high bending and tensile strength, and excellent resistance to ageing and stains.
The edges are made from an ABS compound, fixed with polyurethane glue and rounded.
The standard panels used are classified for reaction to fire in Class 2.
These are available in Rectangular configuration in sizes L.128, 148,168 and 188 x H.105 cm.
Bearing structure composed of two vertical uprights in round tubular steel (diameter 35xD.2 mm) with epoxy powder-coated finishes of Ral 9016 matte
White and Anthracite Mica. The structure comes with caps made from moulded ABS (colours: White or Anthracite).
PLEASE NOTE: for mounting this type of screen it is obligatory to also purchase the CABLE MANAGEMENT TRAY for TABULA HEIGHT-ADJUSTABLE BENCH.
METAL SUSPENDED STORAGE UNITS
Made from bent and welded sheet metal (8/10), available with epoxy powder-coated finishes of Ral 9016 matte White and Anthracite Mica. Inner Metal
drawers mounted on concealed Quadro metal runners (ball slides) with soft closing mechanism. Lock supplied standard on top drawer, complete with
removable barrel and duplicate keys with folding ABS safety key cover grip. Side handled integrated into drawer front.
All units can be attached to the structure and are easy to move thanks to four clips in Nylon 6 + 20% GF (colours: White or Anthracite) mounted on the
top of the unit by a pair of metal brackets to facilitate positioning.
The units are available in the following configurations:
• Single drawer with lock - L.32 x D.50 x H.10 cm
• Two drawers (top drawer with lock) - L.32 x D.50 x H.20 cm
• Single drawer with lock + compartment - L.32 x D.50 x H.40 cm
• Two drawers (top drawer with lock) + compartment - L.32 x D.50 x H.40 cm
P.S.: Compartment size - L.32 x D.50 x H.30 cm
MODESTY PANEL
Made from 18 mm-thick particleboard, with a density of about 650 kg/m³, covered on both sides by a layer of melamine-coated paper (120 g/m²), with
a scratch-proof and anti-reflective surface, in the following finishes: Ivory, Vulcano, Cement Render Effect, Dark Brown Elm, Cream Elm, Black Walnut,
Vulcano, Graphite, Warm Grey, Moss Grey and Petrol Green.
The panels have high bending and tensile strength, and excellent resistance to ageing and stains.
The edges are made from an ABS compound, fixed with polyurethane glue and rounded.
The standard panels used are classified for reaction to fire in Class 2.
The panels can be attached to the structure using a pair of metal brackets (3 mm thick), available in epoxy powder-coated finishes of Ral 9016 matte
White and Anthracite Mica. A clip in Nylon 6 + 20% GF (colours: White or Anthracite) is mounted on each bracket.
DESK MOUNT MONITOR ARM
Made from die-cast aluminium painted White or Black, with strap-on monitor balancing that supports monitors of 0 to 9 kg. Wheel balance adjustment
without the use of tools. 360° rotation lockable at 180° (+90°/-90°). Clip-on monitor attachment plate, 360° rotation and VESA mount 75 &100.
SUSPENDED CPU HOLDER
- BIG model Made from sheet metal, with epoxy powder-coated finish in Ral 9016 matte White. Height adjustment from 37.7 to 53.2 cm.
Width adjustment from 7.8 to 22 cm. Maximum CPU weight - 15 Kg.
- STRAP-ON model composed of a tensioning mechanism complete with black Nylon strap. A metal plate is mounted above the tensioning mechanism.
This is inserted into a second, shaped plate for sliding and rotation. Both plates have an epoxy powder-coated finish in Ral 9006 Aluminium.
Height adjustment from 24 to 50 cm. Width adjustment from 8 to 22.5 cm. Maximum CPU weight - 15 Kg.
All CPU holders can be attached to the structure and are easy to move thanks to four clips in Nylon 6 + 20% GF (colours: White or Anthracite) mounted
by a pair of metal brackets to facilitate positioning.
CABLE DUCTING
CABLE management TRAY for FIXED-HEIGHT BACK TO BACK DESKS (BENCH)
Made from wire (diameter 4 mm) in epoxy powder-coated finishes of Ral 9016 matte White and Anthracite Mica. Four clips in Nylon 6 + 20% GF (colours:
White or Anthracite) mounted on the brackets of the tray are used for attachment to structure.
Available in the following configurations:
• For middle tops: L.60 and 80cm
• For desks: L 140 cm
• For desks: L 160 cm
• For desks: L.180 and 200cm
CABLE management TRAY for SINGLE DESKS
Made from bent sheet metal in epoxy powder-coated finishes of Ral 9016 matte White and Anthracite Mica.
It is fitted with end caps in Nylon 6 + 10% GF (colours: White or Anthracite), with integrated cable clips.
The caps are attached by hinges made from Nylon 6 +10% GF (colours: White or Anthracite) so they can be fixed to the structure and can be rotated.
Available in the following sizes:
• For desks: L.80, 100, 120, 140, 160, 180 and 200 cm
CABLE management TRAY for HEIGHT-ADJUSTABLE BACK TO BACK DESKS (BENCH)
Composed of a tray made from bent sheet metal (130x80 mm) attached to the legs by means of two vertical uprights in round tubular steel (diameter
35 mm) with epoxy powder-coated finishes of Ral 9016 matte White and Anthracite Mica.
The tray is set up to be fit into the front screen holder for height-adjustable Tabula Bench.
Available in the following sizes:
• For desks: L.140, 160, 180 and 200 cm
STANDARD VERTEBRAE for CABLE MANAGEMENT
Made from clear Polycarbonate with total length of 81 cm.
Diameter of base 16.5 cm, made from Aluminium coated metal.
PLUS VERTEBRAE for CABLE MANAGEMENT
Vertical spine cable management system made from Metal and Nylon bristles (black).
Base and attachment made from Zamak with Polished Chrome finish.
TOP ACCESS
Made from Aluminium, with ABS end caps, they come in White or Brill finish. The lid opening comes in the Front version, with integrated soft-closing
mechanism, or in the DOUBLE version (can be opened from either side), thanks to special polycarbonate hinges.
The power strips can be stored in specific cable management trays (optional) or in the cable management trays (for back to back and single desks).
Available in the following sizes: L.26.4 or 45.4 x D.12.5.
All materials used comply with UNI EN standards, and 90% of its production is certified to CARB 2 (formaldehyde emissions).
