DESKS, MEETING TABLES and CONFERENCE TABLES as follows:
LEGS
Consisting of an internal load-bearing structure in press formed steel. To obtain the aesthetic design, the steel framework is inserted into a special
mould and foamed using BayDur60 structural polyurethane with a density of 650 gr/dm3.
Available in three different lacquered finishes:
1. MATT lacquering with a water-based paint, in White RAL9016 and Black RAL9005 finishes
2. METAL lacquering with a water-based paint, in Pewter, Olive Brown and Bronze finishes
The legs can be FIXED or HEIGHT-ADJUSTABLE (see features of Electrical Adjustment system).
They are fitted with 10mm adjustable levellers so they sit perfectly level on the floor.
TOPS
Made from 30 mm-thick MDF with a density of about 800 Kg/m3, available in two different finishes:
1. VENEERED on the top in one of the two wood variants - black WALNUT or EUCALYPTUS. Lacquered on the underside in a finish to match the legs,
using water-based paint. A thick wood trim with rounded edges is applied all around the border. The wood part is coated with a transparent,
water-based matt paint for protection.
2. LACQUERED (using water-based paints) on the top and underside in a finish to match the legs, available with the MATT variant in WHITE or BLACK,
or the METAL variant in BRONZE, PEWTER or OLIVE BROWN.
The panels have high bending and tensile strength, and excellent resistance to ageing and stains.
The standard panels used are classified for reaction to fire Class 2.
FRAMEWORK
The framework - available only in the Polyester Matt Black RAL9005 finish - consists of:
•
two longitudinal steel tubes (100x50x2 mm) shaped using laser tube technology
•
two steel crosspieces (45x25x2 mm)
•
a central receptacle made from press formed steel (450x400xH.75 mm) to store the whole cabling and control box system in the version with
electrical adjustment.
SPECIFICATIONS OF ELECTRICAL ADJUSTMENT SYSTEM
System consisting of four, two-stage rectangular columns (90x60 mm), complete with impact sensor to minimise the risk of damage to the table
when rising and/or descending. Synchronised movement of columns. Invisible inner sliding bearings for smooth, silent movement.
Control box with electronic overload protection and soft start-stop function, stand-by power consumption (0.1 W), interchangeable power cable,
low-profile design (only 35 mm high). A sliding control pad is positioned on the right part of the top.
ROUND TABLES for connections as follows:
LEG
Consisting of a central structure made from a 200xD.3 mm tube processed using laser tube technology, a bottom base made from steel
(390xD.8 mm) and a crosspiece (80x40xD.2 mm) connecting it to the desk.
Available in three different coated finishes:
1. MATT lacquering with a Polyester coating, in White RAL9016 and Black RAL9005 finishes
2. METAL lacquering with a Polyester coating, in Pewter, Olive Brown and Bronze finishes
The leg can be FIXED or HEIGHT-ADJUSTABLE (see features of Electrical Adjustment system).
Felt pads (2.7mm thick) made from POLIT-R are applied to the bottom of the base that sits on the floor.
TOPS
Made from 30mm- thick MDF with a density of about 800 Kg/m3, available in two different finishes:
1. VENEERED on the top in one of the two wood variants - black WALNUT or EUCALYPTUS. Lacquered on the underside in a finish to match the legs,
using water-based paint. A thick wood edge with rounded corners is applied all around the border. The wood part is coated with a transparent,
water-based matt paint for protection.
2. LACQUERED (using water-based paints) on the top and underside in a finish to match the legs, available with the MATT variant in WHITE or BLACK,
or the METAL variant in BRONZE, PEWTER or OLIVE BROWN.
The panels have high bending and tensile strength, and excellent resistance to ageing and stains.
The standard panels used are classified for reaction to fire Class 2.
UPPER SUPPORT TRAY
The upper support TRAY consists of a central receptacle made from press formed steel and a plate (both 2 mm-thick steel) to store the whole
cabling and control box system in the version with electrical adjustment or the multipurpose cabled module in the fixed version.
The basket tray is available only in the Polyester coated Matt Black RAL9005 finish.
SPECIFICATIONS OF ELECTRICAL ADJUSTMENT SYSTEM
System consisting of two, two-stage rectangular columns (90x60 mm), complete with impact sensor to minimise the risk of damage to the table
when rising and/or descending. Synchronised movement of columns. Invisible inner sliding bearings for smooth, silent movement.
Control box with electronic overload protection and soft start-stop function, stand-by power consumption (0.1 W), interchangeable power cable,
low-profile design (only 35 mm high). A sliding control pad is positioned on the right part of the top.
ROUND MEETING TABLES as follows:
LEG
Consisting of a central structure made from a 200xD.3 mm tube processed using laser tube technology, a bottom base made from steel
(390xD.8 mm). Available in three different coated finishes:
1. MATT lacquering with a Polyester coating, in White RAL9016 and Black RAL9005 finishes
2. METAL lacquering with a Polyester coating, in Pewter, Olive Brown and Bronze finishes
The leg can be FIXED or HEIGHT-ADJUSTABLE (see features of Electrical Adjustment system).
Felt pads (2.7mm thick) made from POLIT-R are applied to the bottom of the base that sits on the floor.
TOPS
Made from 30 mm-thick MDF with a density of about 800 Kg/m3, available in two different finishes:
1. VENEERED on the top in one of the two wood variants - black WALNUT or EUCALYPTUS. Lacquered on the underside in a finish to match the legs,
using water-based paint. A thick wood trim with rounded edges is applied around the whole circumference. The wood part is coated with a
transparent, water-based matt paint for protection.
2. LACQUERED (using water-based paints) on the top and underside in a finish to match the legs, available with the MATT variant in WHITE or BLACK,
or the METAL variant in BRONZE, PEWTER or OLIVE BROWN.
The panels have high bending and tensile strength, and excellent resistance to ageing and stains.
The standard panels used are classified for reaction to fire Class 2.
UPPER SUPPORT TRAY
The upper support TRAY consists of a central receptacle made from press formed steel and a plate (both 2 mm-thick steel) to store the whole
cabling and control box system in the version with electrical adjustment or the multipurpose cabled module in the fixed version.
The basket tray is available only in the Polyester coated Matt Black RAL9005 finish.
SPECIFICATIONS OF ELECTRICAL ADJUSTMENT SYSTEM
System consisting of two, two-stage rectangular columns (90x60 mm), complete with impact sensor to minimise the risk of damage to the table
when rising and/or descending. Synchronised movement of columns. Invisible inner sliding bearings for smooth, silent movement.
Control box with electronic overload protection and soft start-stop function, stand-by power consumption (0.1 W), interchangeable power cable,
low-profile design (only 35 mm high). A sliding control pad is positioned on the right part of the top.
DESK RETURN as follows:
LEGS
Consisting of an internal load-bearing structure in press formed steel, with two slots to anchor the structure. To obtain the aesthetic design, the steel
framework is inserted into a special mould and foamed using BayDur60 structural polyurethane with a density of 650 gr/dm3.
Available in three different lacquered finishes:
1. MATT lacquering with a water-based paint, in White RAL9016 and Black RAL9005 finishes
2. METAL lacquering with a water-based paint, in Pewter, Olive Brown and Bronze finishes
The legs are fitted with 10mm adjustable levellers so the unit sits perfectly level on the floor.
FRAMEWORK
The framework consists of two longitudinal steel tubes (100x50x2 mm) shaped using laser tube technology, anchored to the legs with only 4 special
flathead screws. The framework is available only in the Polyester Matt Black RAL9005 finish.
STORAGE UNIT
The STRUCTURE of the RETURN STORAGE UNIT - 30mm-thick MDF with a density of about 800 Kg/m3 - is available in TWO configurations
(3 doors+right drawers or 3 doors+left drawers), both of which come in two different finishes:
1. VENEERED on both sides in one of the two wood variants - black WALNUT or EUCALYPTUS. A thick wood edge with rounded corners is applied all
around the border. The wood part is coated with a transparent, water-based matt paint for protection.
2. LACQUERED on both sides with water-based paint, available with the MATT variant in WHITE or BLACK, BLUE or the METAL variant in BRONZE,
PEWTER or OLIVE BROWN.
The Doors, Drawer Fronts and Backs are shaped all around the edge. This shaping reduces the exposed rim to only 9 mm.
The doors with shaped trim are fitted with special automatic-closing steel hinges mounted on bases for easy adjustment. Push-Pull opening.
On request, they can also be fitted with locks with removable barrel in Nickel finish, with duplicate keys and folding ZAMAK safety key cover with
aluminium coating.
The panels have high bending and tensile strength, and excellent resistance to ageing and stains.
The standard panels used are classified for reaction to fire Class 2.
MODESTY PANEL
Made from 30mm- thick MDF with a density of about 800 Kg/m3, available in two different finishes:
1.
VENEERED on both sides in one of the two wood variants - black WALNUT or EUCALYPTUS. A thick wood edge with rounded corners is applied
all around the border. The wood part is coated with a transparent, water-based matt paint for protection.
2.
LACQUERED (using water-based paints) available with the MATT variant in WHITE or BLACK, or the METAL variant in BRONZE, PEWTER or OLIVE
BROWN.
The panels have high bending and tensile strength, and excellent resistance to ageing and stains.
The standard panels used are classified for reaction to fire Class 2.
The Modesty Panels are attached to the frame using steel shaped plates, available only in the Polyester Matt Black RAL9005 finish.
MEETING CREDENZAS
The Meeting Credenzas - 30mm-thick MDF with a density of about 800 Kg/m3 - are available in TWO configurations (4 doors or 2 doors), both of
which come in two different finishes:
1. VENEERED in one of the two wood variants - black WALNUT or EUCALYPTUS. The wood part is coated with a transparent, water-based matt paint
for protection.
2. LACQUERED (using water-based paints) available with the MATT variant in WHITE or BLACK, or the METAL variant in BRONZE, PEWTER or OLIVE
BROWN.
The Doors and Backs are shaped all around the edge. This shaping reduces the exposed rim to only 9 mm. The doors with shaped trim are fitted with
special automatic-closing steel hinges mounted on bases for easy adjustment, Push-Pull opening, on request, they can also be fitted with locks with
removable barrel in Nickel finish, with duplicate keys and folding ZAMAK safety key cover with aluminium coating.
The backs are painted only around the edges in the same finishes as the structures, which are made from 18 mm-thick MDF, with a density of about
800 kg/m³, laminated on both sides by a layer of melamine-coated paper (120 g/m²), and a scratch-proof and anti-reflective surface finish.
The centre front panel of both the Meeting credenzas is removable for easy access to a cabling tidy.
The panels have high bending and tensile strength, and excellent resistance to ageing and stains.
The standard panels used are classified for reaction to fire Class 2.
