prodotto/
product
tabella di riepilogo prodotti/ product overview table
codice/
code
MPIX2104F300BO
MPIX21044300BO
MPIX21047300BO
colore/
colour
cool white*
cool white*
cool white*
tipo/
type
interni/
interior
interni
interior
interni
interior
LED/
LED
04
04
04
tipo di LED/
LED type
alta emissione/
high emission
alta emissione/
high emission
alta emissione/
high emission
materiale/
material
alluminio/
aluminum
alluminio/
aluminum
alluminio/
aluminum
fascio ottico/
beam angle
10°
25°
40°
ottica/
optic
fissa/
fixed
fissa/
fixed
fissa/
fixed
fissaggio/
fixing
con cassaforma/
with box
con cassaforma/
with box
con cassaforma/
with box
finitura
finishing
bianco/
white
bianco/
white
bianco/
white
IP/
IP
40
40
40
*Disponibile con LED a luce calda su richiesta. / Warm white LED on demand.
applicazioni/
applications
Illuminazione di
ambienti e di locali
pubblici, superfici,
vetrine, corridoi./
Hospitality lighting,
showcases and
corridor.
*Esempio schemi di collegamento a p.344/ Example of wiring diagram on p.344
*codice/code
non inclusi/not included
n. faretti/
n. spots
caratteristiche/
specifications
1
2
3
2
/
alimentatori/LED drivers
WALIMLED 04500
WALIMLED 08500
WALIMLED 12500
WALIM/DIMM/JOLLY
WBOKVAR
10W - 500mA
20W - 500mA - 165x40x25 (h)
26W - 500mA - 260x56x33 (h)
22W - 500mA - 103x67x21 (h) - dimm.
variatore/dimmer 1-10V
69
interior
interni
