Palco InOut
1
3
5
2
4
6
+50°
-30°
140°
355°
+
+
B
Ø
C
AA
B
ø 30
ø 49
ø 83
ø 83
ø 119
ø 137
ø 153
Dimensions
AxB (mm)
53x72
82x90
145x164
145x193
208x253
243x282
276x300
Optics / Technology
Opti Beam Lens
14°/24°
15°/25°
10°/26°
6°/12°/25°
4°/8°/16°/28°
Opti Beam Reflector
40°
16°/26°/45°/80°
40
45°/80°
40°/80°
16°/30°/50°/80°
Accessories
Refractor for elliptical
distribution
•
•
•
•
•
•
•
Diffuser glass
•
•
•
•
•
•
•
Honeycomb louvre
•
•
•
•
•
•
•
Blade louvre
•
•
•
•
•
Cylindrical screen
•
•
•
•
•
•
•
Cylindrical Screen at 45°
•
•
•
•
•
•
DIrectional flap
•
•
•
Frame (directional flaps)
•
•
•
Protection grille
•
•
•
Mounting accessories
Spike
•
•
•
•
•
Spike with driver
•
•
On pole with arms
single (1) / double (2)
•
•
•
•
On pole with flange
single (3) / double (4)
•
•
•
•
Wall-mounted with double
(5) / triple (6) support
•
•
•
•
Insulation Class
Class III
•
•
•
Class II (complete with
power supply)
•
•
•
•
MultiPalco InOut
possible installations
on poles 5000 / 6000 /
7000 / 8000 / 9000 /
10000 / 12000 mm
(dimensions refer to the
height of the pole above
ground)
for more information visit
iguzzini.com/palco-inout
installation alternatives
with single / double arm
installation alternatives
with single / double flange
Solid thinking
Sturdiness, versatility and functionality
Palco InOut is designed to work in any setting. Each
internal accessory is housed in a gasket and has protective
glass to prevent penetration by dust and therefore the
upkeep of the product's IP66 grade. The external
accessories, on the other hand, have a hole to drain water
and a screen to prevent the emission of stray light.
The High Output and High Resistance versions make it
possible to adapt luminous fluxes to outdoor
temperatures from +35 °C to +50 °C and from -20 °C to
-30 °C. Spike installation is also possible stake with full
integration, thereby significantly simplifying the system.
Dual rotation to ensure maximum flexibility and versatility.
Thermal resistance
Reliability even at extreme
temperatures
IP66
Each internal accessory is housed
in a gasket to ensure upkeep of
the product's IP66 grade.
Spike installation
Even including integrated power
supply to simplify and speed up
installation.
Dual rotation
The product can rotate on vertical
and horizontal surfaces alike,
thereby ensuring maximum
flexibility and versatility.
