Lighting collection
156
Lighting collection
157
DETAILS
• Central component made of transparent
or grey resin, Ø9 cm.
• The metal lamp shade can be personalized.
• Pendant energy-saving LED light
(Energy efficiency index A).
• Standard total height cm 180h.
LIGHT SOURCE
• GU10 10 LED bulb
• Upon request available with extra warm
light 2700 K.
• Available 110 V upon request, bulbs not included.
• Phase cut dimmable.
DETTAGLI
• Componente centrale in resina trasparente
o grigia, Ø9 cm.
• Il paralume in metallo è personalizzabile.
• Lampada a sospensione a LED a risparmio
energetico (Indice di efficienza energetica A).
• Altezza totale standard cm 180h.
FONTE LUMINOSA
• Lampadina GU10 10 LED
• Su richiesta disponibile con luce extra calda 2700 K.
• Disponibile 110 V su richiesta, lampadine
non incluse.
• Dimmerabile a taglio di fase.
A central cylindrical body in resin, matched with hand-burnished metals, becomes a
vivid and intense note that fascinates with the unexpected possibilities of chromatic
transformations provoked by the light. Its totemic presence, on a table or pendant,
single or replicated, confers to any interior special accents of identity.
Un corpo cilindrico centrale in resina, abbinato a metalli bruniti a mano, diventa una
nota vivida e intensa che affascina per le inaspettate possibilità di trasformazioni
cromatiche provocate dalla luce. La sua presenza totemica, su un tavolo o pendente,
singolo o replicato, conferisce a qualsiasi interno speciali accenti di identità.
GHOST
CHANDELIERS
CONSTRUCTION
SPECIFICATION
Weight:
Material:
Finish:
5.5-7.3 kg
• Light diffuser in metal
• Central element in resin, in transparent
and grey colour
Black Burnished Steel, Burnished Platino, Burnished
Titanio, Burnished Brass, Black Burnished Brass,
H-Silver, H-Silver Black
Certified Product
Prodotto certificato
IP20
TECHNICAL DATA
Net Weight:
Light source:
Input Voltage [V]:
Max Power [W]:
Light colour [K]:
Flux [lm]:
CRI:
Dimming:
7.2 kg
GU10 led bulb
220-240 V or 110-120 V upon request
6 W
3000 K or 2700 K upon request
700 lm**
>80
Phase-cut dimmable
Ø18
63
27
9
TECHNICAL DATA
Net Weight:
Light source:
Input Voltage [V]:
Max Power [W]:
Light colour [K]:
Flux [lm]:
CRI:
Dimming:
5.5 kg
GU10 led bulb
220-240 V or 110-120 V upon request
6 W
3000 K or 2700 K upon request
700 lm**
>80
Phase-cut dimmable
Ø12
66
40
9
TECHNICAL DATA
Net Weight:
Light source:
Input Voltage [V]:
Max Power [W]:
Light colour [K]:
Flux [lm]:
CRI:
Dimming:
7.3 kg
GU10 led bulb
220-240 V or 110-120 V upon request
6 W
3000 K or 2700 K upon request
700 lm**
>80
Phase-cut dimmable
62
Ø30
20
9
**Output of led inside the lamp. Losses due to diffusor and reflectors are not considered. Values are indicative, ambient temperature, height and position of the lamp may vary the values.
**Emissione del LED all’interno della lampada. Le perdite dovute a diffusore e riflettori non sono considerate. I valori sono indicativi: temperatura ambiente, altezza e posizione della lampada possono
influenzare i valori.
DESIGNER
Massimo Castagna
12.3
2.5
Ø12.3
Canopy
