DETAILS
• Irregular polyhedral shape tubes made of Murano
Glass cm 85h.
• Transparent or Grey Glass.
• Available in 3 different configurations.
• Total height including metal stems cm 180h.
LIGHT SOURCE
• Led bulb light G9 3000K, phase cut dimmable.
• Optional led bulb 2700 K.
• Available upon request 110V.
DETTAGLI
• Tubi di forma poliedrica irregolare in Vetro di Murano
cm 85h.
• Vetro Trasparente o Grigio.
• Disponibile in 3 diverse configurazioni.
• Altezza totale compresi steli in metallo cm 180h.
FONTE LUMINOSA
• Lampadina a led G9 3000K, dimmerabile
a taglio di fase.
• Lampadina led opzionale 2700 K.
• Disponibile su richiesta 110V.
From a synthesis between materiality and transparency emerges a strong stage
presence. Delicate polyhedral glass diffusers blown by masters of Murano,
suspended from a brass support structure, display a magnetic allure, radiating with
a choreographic three-dimensional play of swirls and reflections a sophisticated and
precious aura.
Da una sintesi tra materialità e trasparenza emerge una forte presenza scenica. Delicati
diffusori poliedrici in vetro soffiato da maestri muranesi, sospesi ad una struttura
portante in ottone, manifestano un’allure magnetica, irradiando con un coreografico
gioco tridimensionale di volute e riflessi un’aura sofisticata e preziosa.
AIRLIGHT
CHANDELIERS
CONSTRUCTION
SPECIFICATION
Weight:
Material:
Finish:
6.3-117.3 kg
Metal and Glass
• Burnished Brass-Transparent Glass
• Black Burnished Steel-Grey Glass
20x20
40x40
40x60
6h
6h
Canopy
Certified Product
Prodotto certificato
IP20
TECHNICAL DATA
Net Weight:
Light source:
Input Voltage [V]:
Max Power [W]:
Light colour [K]:
Flux [lm]:
CRI:
Dimming:
22.2 kg (A 6.3 kg/B 7.4 kg/C 8.5 kg)
G9 led bulb
220-240 V or 110-120 V upon request
9 W-2700 K/12 W-3000 K
2700 K or 3000 K
2700 K-750 lm/3000 K-990 lm**
80
Dimmable (phase cut for 2700K only),
not dimmable 3000 K
180
20x20
85
B
C
A
TECHNICAL DATA
Net Weight:
Light source:
Input Voltage [V]:
Max Power [W]:
Light colour [K]:
Flux [lm]:
CRI:
Dimming:
117.3 kg
G9 led bulb
220-240 V or 110-120 V upon request
48 W-2700 K/64 W-3000 K
2700 K or 3000 K
2700 K-4000 lm/3000 K-5.280 lm**
80
Dimmable (phase cut for 2700 K only),
not dimmable 3000 K
180
85
40x40
TECHNICAL DATA
Net Weight:
Light source:
Input Voltage [V]:
Max Power [W]:
Light colour [K]:
Flux [lm]:
CRI:
Dimming:
88.8 kg
G9 led bulb
220-240 V or 110-120 V upon request
36 W-2700 K/48 W-3000 K
2700 K or 3000 K
2700 K-3000 lm/3000 K-3.960 lm**
80
Dimmable (phase cut for 2700 K only),
not dimmable 3000 K
180
40x60
85
6 Elements
4 Elements
1 Element
**Output of led inside the lamp. Losses due to diffusor and reflectors are not considered. Values are indicative, ambient temperature, height and position of the lamp may vary the values.
**Emissione del LED all’interno della lampada. Le perdite dovute a diffusore e riflettori non sono considerate. I valori sono indicativi: temperatura ambiente, altezza e posizione della lampada possono
influenzare i valori.
DESIGNER
Massimo Castagna
