Lighting collection
90
Lighting collection
91
A central cylindrical body in resin, matched with
hand-burnished metals, becomes a vivid and intense note that fascinates with the
unexpected possibilities of chromatic transformations provoked by the light. Its totemic
presence, on a table or pendant, single or replicated, confers to any interior special
accents of identity.
Un corpo cilindrico centrale in resina, abbinato a metalli bruniti a mano, diventa una
nota vivida e intensa che affascina per le inaspettate possibilità di trasformazioni
cromatiche provocate dalla luce. La sua presenza totemica, su un tavolo o pendente,
singolo o replicato, conferisce a qualsiasi interno speciali accenti di identità.
DETAILS
• Central component made of transparent or grey
resin, Ø 9 cm.
• The metal lamp shade can be personalized.
• Pendant energy-saving LED light (Energy efficiency
index A).
• Standard total height cm 180h.
LIGHT SOURCE
• AC LED BOARD 3000 K - 220-240V
• Upon request available with extra warm light
2700 K.
• Upon request available 110-120 V.
• Wired version not dimmable, rechargable version
touch dimmable.
DETTAGLI
• Componente centrale in resina trasparente o grigia,
Ø 9 cm.
• Il paralume in metallo può essere personalizzato.
• Sospensione a led a risparmio energetico (Indice di
efficienza energetica A).
• Altezza totale standard cm 180h.
FONTE LUMINOSA
• SCHEDA LED AC 3000 K - 220-240V
• Su richiesta disponibile con luce extra calda 2700 K.
• Su richiesta disponibile 110-120 V.
• Versione cablata non dimmerabile, versione
ricaricabile touch dimmerabile.
GHOST LAMP
CONSTRUCTION
SPECIFICATION
Weight:
Material:
Finish:
3,90 kg-4,20 kg
• Lampshade in metal
• Central element in transparent or grey resin
Black Burnished Steel, Burnished Titanio,
Burnished Platino, Burnished Brass, Black Burnished Brass,
H-Silver, H-Silver Black
Certified Product
Prodotto certificato
IP20
TECHNICAL DATA
Net Weight:
Light source:
Input Voltage [V]:
Max Power [W]:
Light colour [K]:
Flux [lm]:
CRI:
Dimming:
3.9 kg
AC LED BOARD
220-240 V or 110-120 V upon request
4.5 W
3000 K or 2700 K upon request
456 lm**
(275 lm for rechargeable lamp)
>80
On/Off. Touch switch dimmable for
rechargeable version only
Ghost Lamp Ø25
Available in a
rechargeable version
25
38
TECHNICAL DATA
Net Weight:
Light source:
Input Voltage [V]:
Max Power [W]:
Light colour [K]:
Flux [lm]:
CRI:
Dimming:
4.2 kg
AC LED BOARD
220-240 V or 110-120 V upon request
4.5 W
3000 K or 2700 K upon request
456 lm**
(275 lm for rechargeable lamp)
>80
On/Off. Touch switch dimmable for
rechargeable version only
Ghost Lamp Ø38
Available in a
rechargeable version
45
38
TABLE AND FLOR LAMPS
**Output of led inside the lamp. Losses due to diffusor and reflectors are not considered. Values are indicative, ambient temperature, height and position of the lamp may vary the values.
**Emissione del LED all’interno della lampada. Le perdite dovute a diffusore e riflettori non sono considerate. I valori sono indicativi: temperatura ambiente, altezza e posizione della lampada possono
influenzare i valori.
DESIGNER
Massimo Castagna
