TECHNICAL DATA
Net Weight:
Light source:
Input Voltage [V]:
Max Power [W]:
Light colour [K]:
Flux [lm]:
CRI:
Dimming:
8 kg-12 kg
COB led
220-240 V or 110-120 upon request
48 W
3000 K or 2700 K upon request
2700 K-4320 lm; 3000 K-4560 lm**
>80
DMX; dimmable 1-10 V; dimmable 0-10 V;
DALI; dimmable push
12 Elements-Ø23,5/Ø40
216
216
130
130
TECHNICAL DATA
Net Weight:
Light source:
Input Voltage [V]:
Max Power [W]:
Light colour [K]:
Flux [lm]:
CRI:
Dimming:
1 kg
COB led
220-240 V or 110-120 upon request
4 W
3000 K or 2700 K upon request
2700 K-360 lm; 3000 K-380 lm**
>80
DMX; dimmable 1-10 V; dimmable 0-10 V;
DALI; dimmable push
1 Element-Ø40
Ø40
**Output of led inside the lamp. Losses due to diffusor and reflectors are not considered. Values are indicative, ambient temperature, height and position of the lamp may vary the values.
**Emissione del LED all’interno della lampada. Le perdite dovute a diffusore e riflettori non sono considerate. I valori sono indicativi: temperatura ambiente, altezza e posizione della lampada possono
influenzare i valori.
