Lighting collection
30
Lighting collection
31
A clear, sleek, distinctive sign expresses the wall lights, Gladio, long glass trihedrons
framed by titanium bands; stylized icons privileging a pure beauty.
Un segno netto, slanciato, distintivo esprime le applique Gladio, lunghi triedri di vetro
incorniciati da bande di titanio; icone stilizzate che privilegiano una pura bellezza.
DETAILS
• Dimmable wall light made of metal or stone with a
trihedron Murano glass.
• Energy-saving LED light (Energy efficiency index A).
• Transformer included in the wall box.
LIGHT SOURCE
• LED 24 V - 3000 K.
• Upon request available with extra
warm light 2700 K.
• Upon request available 110 V.
• Dimming function included.
DETTAGLI
• Lampada da parete dimmerabile in metallo con un
triedro in vetro di Murano.
• LED a risparmio energetico (Indice di efficienza
energetica A).
• Trasformatore integrato nel box a muro.
FONTE LUMINOSA
• Strip led 24 V, luce calda 3000 K.
• Su richiesta disponibile con luce extra calda a
2700 K.
• Disponibile 110 V su richiesta.
• Dimmerabile.
GLADIO
CONSTRUCTION
SPECIFICATION
Weight:
Material:
Finish:
9.7-12.5 kg
Brass, steel or stone profile with a trihedron
of Murano glass diffuser
• Burnished Titanio, Burnished Platino, Burnished Brass,
Black Burnished Brass, H-Silver Patina, H-Pale Gold
• Stones from our range
Certified Product
Prodotto certificato
IP20
TECHNICAL DATA
Net Weight:
Light source:
Input Voltage [V]:
Max Power [W]:
Light colour [K]:
Flux [lm]:
CRI:
Dimming:
9.7-12.5 kg
strip LED 24 V
220-240 V or 110-120 V upon request
16 W
3000 K or 2700 K upon request
2700 K - 1205 lm / 3000 K - 1323 lm**
>90
Push / Phase cut / 0-10 V / 1-10 V /
DMX / DALI-2 dimmable
5
150
11
**Output of led inside the lamp. Losses due to diffusor and reflectors are not considered. Values are indicative, ambient temperature, height and position of the lamp may vary the values.
**Emissione del LED all’interno della lampada. Le perdite dovute a diffusore e riflettori non sono considerate. I valori sono indicativi: temperatura ambiente, altezza e posizione della lampada possono
influenzare i valori.
WALL LIGHT
DESIGNER
Ugo Cacciatori
