Lighting collection
254
Lighting collection
255
DETAILS
• Ceiling led light made of Burnished Brass.
• Energy-saving LED light (energy efficiency index A).
• Transformer incorporated in the lamp.
LIGHT SOURCE
• COB LED 24V 3000K.
• Upon request available with extra warm light 2700K.
• Available 110V upon request.
• Dimming function included.
DETTAGLI
• Lampada a soffitto a led realizzata in Ottone Brunito.
• Led a risparmio energetico (Indice di efficienza
energetica A).
• Trasformatore incorporato
FONTE LUMINOSA
• COB LED 24V 3000K.
• Su richiesta disponibile con luce extra
calda a 2700K.
• Disponibile 110V su richiesta.
• Dimmerabile.
Compact cylindrical bodies, and pure geometries, resonate with accents of strong
personality. Minimalism and sophistication, enhanced by special, refined finishes,
express Tele Light, an intriguing micro-sculpture, in single or grouped presence.
Corpi cilindrici compatti, e geometrie pure, risuonano di accenti di forte personalità.
Minimalismo e raffinatezza, esaltati da particolari e raffinate finiture, esprimono Tele
Light, un’intrigante micro-scultura, in presenza singola o in gruppo.
TELE
CHANDELIERS
CONSTRUCTION
SPECIFICATION
Weight:
Material:
Finish:
2.1-2.5 kg
Brass cylinder
Burnished Brass, Black Burnished Brass,
Burnished Titanio, Burnished Platino
Certified Product
Prodotto certificato
IP20
TECHNICAL DATA
Net Weight:
Light source:
Input Voltage [V]:
Max Power [W]:
Light colour [K]:
Flux [lm]:
CRI:
Dimming:
2.5 kg
COB led 240 mA
220-240 V or 110-120 upon request
9 W
3000 K or 2700 K upon request
2700 K-1188 lm; 3000 K-1217 lm**
>80/>90 upon request
Push/Phase cut/0-10 V/1-10 V/
DMX/DALI-2 dimmable
34
9
TECHNICAL DATA
Net Weight:
Light source:
Input Voltage [V]:
Max Power [W]:
Light colour [K]:
Flux [lm]:
CRI:
Dimming:
2.1 kg
COB led 240 mA
220-240 V or 110-120 upon request
9 W
3000 K or 2700 K upon request
2700 K-1188 lm; 3000 K-1217 lm**
>80/>90 upon request
Push/Phase cut/0-10 V/1-10 V/
DMX/DALI-2 dimmable
26
12
**Output of led inside the lamp. Losses due to diffusor and reflectors are not considered. Values are indicative, ambient temperature, height and position of the lamp may vary the values.
**Emissione del LED all’interno della lampada. Le perdite dovute a diffusore e riflettori non sono considerate. I valori sono indicativi: temperatura ambiente, altezza e posizione della lampada possono
influenzare i valori.
DESIGNER
Massimo Castagna
