Lighting collection
230
Lighting collection
231
TECHNICAL DATA
Net Weight:
Light source:
Input Voltage [V]:
Max Power [W]:
Light colour [K]:
Flux [lm]:
CRI:
Dimming:
9.6 kg
strip LED 24 V
220-240 V or 110-120 V upon request
47.04 W
3000 K or 2700 K upon request
2700 K - 12124 lm / 3000 K - 12796 lm**
>90
Push / Phase cut / 0-10 V / 1-10 V / DMX /
DALI-2 dimmable
Starlight Horizontal
B MAXI
180
100
201
TECHNICAL DATA
Net Weight:
Light source:
Input Voltage [V]:
Max Power [W]:
Light colour [K]:
Flux [lm]:
CRI:
Dimming:
10.1 kg
strip LED 24 V
220-240 V or 110-120 V upon request
50.4 W
3000 K or 2700 K upon request
2700 K - 12990 lm / 3000 K - 13710 lm**
>90
Push / Phase cut / 0-10 V / 1-10 V / DMX /
DALI-2 dimmable
Starlight Horizontal
C MAXI
136
180
226
TECHNICAL DATA
Net Weight:
Light source:
Input Voltage [V]:
Max Power [W]:
Light colour [K]:
Flux [lm]:
CRI:
Dimming:
18 kg
strip LED 24 V
220-240 V or 110-120 V upon request
58.8 W
3000 K or 2700 K upon request
2700 K - 15155 lm / 3000 K - 15995 lm**
>90
Push / Phase cut / 0-10 V / 1-10 V / DMX /
DALI-2 dimmable
Starlight Horizontal
XL A
180
174
262
TECHNICAL DATA
Net Weight:
Light source:
Input Voltage [V]:
Max Power [W]:
Light colour [K]:
Flux [lm]:
CRI:
Dimming:
18 kg
strip LED 24 V
220-240 V or 110-120 V upon request
58.8 W
3000 K or 2700 K upon request
2700 K - 15155 lm / 3000 K - 15995 lm**
>90
Push / Phase cut / 0-10 V / 1-10 V / DMX /
DALI-2 dimmable
Starlight Horizontal
XL B
180
156
305
TECHNICAL DATA
Net Weight:
Light source:
Input Voltage [V]:
Max Power [W]:
Light colour [K]:
Flux [lm]:
CRI:
Dimming:
18 kg
strip LED 24 V
220-240 V or 110-120 V upon request
58.8 W
3000 K or 2700 K upon request
2700 K - 15155 lm / 3000 K - 15995 lm**
>90
Push / Phase cut / 0-10 V / 1-10 V / DMX /
DALI-2 dimmable
Starlight Horizontal
XL C
311
126
180
TECHNICAL DATA
Net Weight:
Light source:
Input Voltage [V]:
Max Power [W]:
Light colour [K]:
Flux [lm]:
CRI:
Dimming:
23 kg
strip LED 24 V
220-240 V or 110-120 V upon request
94.08 W
3000 K or 2700 K upon request
2700 K - 24248 lm / 3000 K - 25592 lm**
>90
Push / Phase cut / 0-10 V / 1-10 V / DMX /
DALI-2 dimmable
Starlight Horizontal
XL A MAXI
405
249
180
TECHNICAL DATA
Net Weight:
Light source:
Input Voltage [V]:
Max Power [W]:
Light colour [K]:
Flux [lm]:
CRI:
Dimming:
24.7 kg
strip LED 24 V
220-240 V or 110-120 V upon request
107.52 W
3000 K or 2700 K upon request
2700 K - 27712 lm / 3000 K - 29248 lm**
>90
Push / Phase cut / 0-10 V / 1-10 V / DMX /
DALI-2 dimmable
Starlight Horizontal
XL B MAXI
483
280
180
TECHNICAL DATA
Net Weight:
Light source:
Input Voltage [V]:
Max Power [W]:
Light colour [K]:
Flux [lm]:
CRI:
Dimming:
22.2 kg
strip LED 24 V
220-240 V or 110-120 V upon request
101.64 W
3000 K or 2700 K upon request
2700 K - 26196.5 lm / 3000 K - 27648.5 lm**
>90
Push / Phase cut / 0-10 V / 1-10 V / DMX /
DALI-2 dimmable
Starlight Horizontal
XL C MAXI
459
266
180
**Output of led inside the lamp. Losses due to diffusor and reflectors are not considered. Values are indicative, ambient temperature, height and position of the lamp may vary the values.
**Emissione del LED all’interno della lampada. Le perdite dovute a diffusore e riflettori non sono considerate. I valori sono indicativi: temperatura ambiente, altezza e posizione della lampada possono
influenzare i valori.
