Microwave oven 200 series
BM P 224/BM P 225
Controls at the bottom
Right-hinged
BM P 224 100
Full glass door in Gaggenau
Anthracite.
Width 60 cm.
BM P 224 110
Full glass door in Gaggenau Metallic.
Width 60 cm.
BM P 224 130
Full glass door in Gaggenau Silver.
Width 60 cm.
Left-hinged
BM P 225 100
Full glass door in Gaggenau
Anthracite.
Width 60 cm.
BM P 225 110
Full glass door in Gaggenau Metallic.
Width 60 cm.
BM P 225 130
Full glass door in Gaggenau Silver.
Width 60 cm.
Included in the price
1 glass tray.
1 wire rack.
Highlights
— Flush installation.
— Handleless door / automatic door
opening.
— Single operation and combination
of microwave and grill.
— Sequential operation of up to
5 modes incl. programming of
combined operation and rest time.
— TFT touch display.
— Electronic temperature control.
— Interior volume 21 litres.
Programmes
Microwave operation with 5 output
levels: 900, 600, 360, 180, 90 W.
Full surface grill with 3 levels of
intensity, maximum output 1300 W.
Full surface grill with microwave
output levels 360, 180 and 90 W
combinable.
10 automatic programmes with weight
indication:
3 defrosting programmes
4 cooking programmes
3 combination programmes
Option to save individual recipes.
Handling
Automatic door opening.
Rotary knob and TFT touch display
operation.
Clear text display.
Information key with use indicators.
Side-opening door opens up to
110° angle.
Features
Innowave.
Actual temperature display.
25 W interior light.
Hygienic stainless steel interior with
glass ceramic base.
Safety
Thermally insulated door with double
glazing.
Child lock.
Safety shut-off.
Cooled housing with temperature
protection.
Planning notes
Door hinge not reversible.
Minimum installation height 85 cm
(top edge of niche bottom).
Height-adjustable feet.
Installation of BMP above BOP with
intermediate shelf.
Necessary lateral gap between
appliance door and furniture panel of
min. 5 mm.
The door panel surface of the
appliance extends 21 mm from the
furniture cavity.
When planning a corner solution, pay
attention to the side-opening door
and the minimum required distance
to the wall.
Please read the installation details
regarding oven combination on
page 14–15.
Connection
Total connected load 2.0 kW.
Connection cable 1.7 m, pluggable.
Ovens 200 series
70
