All measurements in mm.
Wine climate cabinet 200 series
R W 222
R W 222 263
Fully integrated, with glass door.
Niche width 56 cm,
Niche height 123 cm.
Installation accessories
R A 221 211
Stainless steel door panel with handle.
For RW 222, panel thickness 19 mm.
R A 425 910
Handle bar, stainless steel, short.
For RVY 497, RB 492 and RW 222,
with 2 mounts, length 810 mm,
height 49 mm, drilling distance
between the mounts 787 mm.
Special accessories
R A 050 220
Replacement activated charcoal air
filter.
A
G
Highlights
— 2 independently controllable
climate zones.
— Consistent temperatures with
exact control from +5 °C to +20 °C.
— Humidity control.
— Extendable bottle trays in beech
and aluminium.
— Presentation light option.
— Low-vibration operation.
— Number of standard wine bottles: 48.
Handling
Electronic temperature control with
digital display.
Touch keys.
Presentation light option in each
climate zone, dimmable.
Interior LED lighting (3000 K) with
automatic dimming with opening and
closing of door.
Technical features
Dynamic cold air distribution.
Automatic defrosting with defrost
water evaporation.
Cushioned door closing system
integrated in door hinge.
1 activated charcoal air filter for both
climate zones.
UV-protection.
Open-door and malfunction alarm.
Child lock.
Features
Capacity 48 bottles
(based on 0.75 l standard bottles).
6 bottle trays, 4 of which are
extendable.
Storage of magnum bottles possible.
LED lighting.
Total volume 159 litres.
Consumption data
Energy efficiency class G at a range of
energy efficiency classes from A to G.
Energy consumption 151 kWh/year.
Noise level 32 dB (A) re 1 pW.
Planning notes
Flat hinge.
Door hinge right, reversible.
Height-adjustable feet.
Door opening angle of 115°,
fixable at 90°.
Max. door panel weight 20 kg.
Door panel thickness
min. 16 mm/max. 22 mm.
The mains socket needs to be planned
outside the built-in niche.
For a side-by-side installation every
appliance must be planned in its own
niche.
When combining the wine climate
cabinet with cooling appliances other
than a second wine climate cabinet, a
clearance of min. 150 mm is to be kept
between the appliances to avoid
condensation.
No transport/operation above 1500 m
sea level.
Connection
Total connected load 0.130 kW.
Connecting cable 2.0 m with plug.
A: Suitable area for storage of magnum bottles
B:
Measurements in mm
0.75 litres
Bottle storage
(
A
)
(
A
)
(
A
)
(
B
)
300
215
ø 30
ø 75
A: Suitable area for storage of magnum bottles
B:
Measurements in mm
0.75 litres
Bottle storage
(
A
)
(
A
)
(
A
)
(
B
)
300
215
ø 30
ø 75
A: Suitable area for storage of magnum bottles
B:
Measurements in mm
0.75 litres
Bottle storage
(
A
)
(
A
)
(
A
)
(
B
)
300
215
ø 30
ø 75
