All measurements in mm.
Vacuuming drawer 400 series
D V 061
D V 061 100*
Fully integrated.
Width 60 cm, Height 14 cm.
* Suitable for 400 and 200 series
Included in the price
50 vacuuming bags, small.
50 vacuuming bags, big.
1 raised vacuuming platform.
1 adaptor f. vacuuming outside the
chamber.
1 vacuuming hose.
1 adaptor for bottle plugs.
3 plugs for vacuuming of bottles.
Highlights
— Integrable in 14 cm high niche.
— Hygienic stainless steel vacuuming
chamber, applicable height up to
80 mm.
— 3 vacuuming levels for vacuuming
in the chamber, max. 99%.
— 3 vacuuming levels for vacuuming
outside the chamber, max. 90%.
— Automatic connection recognition
for vacuuming outside the
chamber.
— Cushioned closing system.
Application
Vacuuming for sous-vide cooking.
Vacuuming for fast marinating and
flavouring.
Vacuuming for extended storage.
Vacuuming of vacuuming containers
outside the chamber.
Vacuuming of liquids in bottles outside
the chamber.
Handling
Touch key operation.
Features
Net volume 7 litres.
Capacity load max. 10 kg.
Maximum size of vacuuming bags
W 240 mm x L 350 mm.
3 heat-sealing levels for different
strengths of bag material.
Sealing bar, non-stick coating,
removable.
Safety glass cover, opens automati-
cally after vacuuming.
Raised vacuuming platform, 44 mm,
deployable.
Utility space in vacuuming chamber,
W 210 mm x L 275 mm.
Membrane for avoiding reflow of
liquids during vacuuming outside the
chamber.
Drying programme for vacuuming
pump.
Warning function.
Planning notes
Attention: To open the fully integrated
variant, a handle or a recessed grip is
required.
The thickness of the furniture panel is
at least 19 mm.
The width of the furniture panel is
590–596 mm.
The recommended height of the
furniture panel is 142–156 mm.
Front weight up to 3 kg.
Installation of BS/BM/CM directly
above DV in 59 cm niche without
intermediate floor.
Built-in under worktop or in single
niche.
The socket can be planned behind the
appliance.
Special accessories
(order as spare parts):
Part No. 00578813
vacuuming bags, small
Part No. 00578814
vacuuming bags, big
Please read the installation details
regarding oven combination on
page 14–15.
Connection
Total connected load 0.32 kW.
Connection cable 1.5 m, pluggable.
