All measurements in mm.
Vario fridge-freezer combination
200 series
R B 289
R B 289 300
With fresh cooling close to 0 °C.
Fully integrated.
Niche width 56 cm,
Niche height 177.5 cm.
Included in the price
2 bottle supports, maple wood.
2 egg trays.
1 ice cube tray.
2 ice packs.
Special accessories
R A 430 100
Storage container with transparent
lid, anthracite.
R A 238 030
Solid maple bottle support with
magnetic connector, oiled.
R A 260 000
Heavy duty hinge support for a
maximum door weight of 24 kg.
A
G
Highlights
— Interior with precision-fitted, solid
aluminium elements in Gaggenau
Light Bronze.
— Extendable shelves and drawers.
— Warm white and glare-free LED
light.
— 4 climate zones incl. 2 fresh cooling
drawers close to 0 °C.
— Height-adjustable, extendable
safety glass shelves, set in solid
aluminium profiles.
— Cushioned door closing system
allowing a soft and controlled door
closure.
— Easy-glide, fully extendable
telescopic pull-out racks and a
cushioned closing system allowing
soft and controlled drawer closure.
— Solid maple bottle supports with
magnetic connector.
— Total volume 223 litres.
Handling
Electronic temperature control with
digital display.
Touch keys.
Technical features
Automatic defrosting with defrost
water evaporation.
Cushioned door closing system from
20° door opening angle, integrated in
door hinge.
Open-door and malfunction alarm.
Holiday mode.
Selected digital services
(Home Connect)
Remote control and monitoring.
Please read additional information on
Home Connect on page 409.
Cooling
Fast cooling.
Temperature adjustable from
+3 °C to +8 °C.
2 height-adjustable safety glass
shelves, partly extendable.
1 frosted white glass shelf.
2 oiled, solid maple bottle supports
with magnetic connector, can be
increased to 5 supports per shelf.
A total of 9 bottles (based on a 0.75 l
bottle) can be stored on one level
using 5 bottle supports.
The bottle supports are also suitable
for storing champagne bottles and
magnums.
1 large aluminium door rack for bottles.
1 aluminium door rack.
Warm white interior lighting (3500 K)
with integrated glare-free LED side
lights.
Volume 101 litres.
Fresh cooling close to 0 °C
Drawers with solid aluminium handles
and signature drawer front with a
gradual frosted surface.
1 fully extendable fresh cooling
drawer close to 0 °C, illuminated.
Humidity can be adjusted manually.
Ideal for fruit and vegetables.
1 fully extendable fresh cooling
drawer close to 0 °C, illuminated.
Ideal for meat, fish and poultry.
Volume 55 litres.
Freezing
No-frost technology with fast freezing.
Temperature adjustable
from -24 °C to -14 °C.
4-star freezer compartment.
Drawers with solid aluminium handles
and signature drawer front with a
gradual frosted surface.
Defrost assistance.
Freezing capacity 7 kg/24 h.
Storage time after a malfunction 8 h.
3 freezer drawers, 1 of which extra
large.
2 safety glass shelves.
Volume 67 litres.
Consumption data
Energy efficiency class D at a range of
energy efficiency classes from A to G.
Energy consumption 201 kWh/year.
Noise level 37 dB (A) re 1 pW.
Planning notes
Flat hinge.
Door hinge right, reversible.
Door opening angle of 115°,
fixable at 90°.
Max. door panel weight:
Upper door 19 kg. Lower door 19 kg.
Please read additional planning notes
on page 349.
Connection
Total connected load 0.090 kW.
Connecting cable 2.3 m with plug.
min. 200 cm²
min. 40
max. 2200
560
recommended
(min. 550)
min. 200 cm²
min. 560
1772+8
1772
697
545
558
1016
703
731
Cooling appliances
336
