Fridge-freezer combination
dark brushed stainless steel
RV Y 497
RV Y 497 190
Fully integrated.
Niche width 90 cm,
Niche height 213.4 cm.
Cooling compartment with two doors
and one fully extendable freezing
drawer.
Included in the price
1 egg holder with lid.
1 ice cube scoop.
1 ethylene absorber.
2 bottle supports, oak wood.
Installation accessories
R A 425 110
Handle bar, stainless steel, long.
With 3 mounts, length 1.131 mm,
height 49 mm, drilling distance
between each mount 554 mm.
R A 425 910
Handle bar, stainless steel, short.
For RVY 497, RB 492 and RW 222,
with 2 mounts, length 810 mm, height
49 mm, drilling distance between the
mounts 787 mm.
R A 460 030
Connecting element for vertically
split fronts (for fridge-freezer
combination).
RV A 423 141
Side trims, 3 mm. 2 pieces.
RV A 421 922
Door panels, dark brushed stainless
steel, with handles.
For RVY 497, panel thickness 19 mm.
RV A 428 922
Door panels, dark brushed stainless
steel, handleless.
For RVY 497, panel thickness 19 mm.
RV A 460 000
Accessory for side-by-side installation.
For RVY 497.
RV A 460 020
Accessory for side-by-side
installation, backward compatible.
Required if a RVY 497 is installed
side-by-side with a RY, RB, RC, RF or
RW of the Vario cooling 400 series.
A
G
RV A 460 900
Accessory for replacement
side-by-side installation in unmodified
niche.
Required if a RVY 497 (89.4 cm wide) is
installed side-by-side into a niche
which was formerly housing a
combination including a RY 492,
RB 492 or RC 492 (90.8 cm wide).
RV A 460 910
Accessory for replacement in single
unmodified niche.
Required if a RVY 497 (89.4 cm wide) is
replacing a RY 492, RB 492 or
RC 492 (90.8 cm wide).
Special accessories
ACLETHRF10
Ethylene absorber.
Refill kit.
For placement in a fresh climate
drawer.
ACLETHST10
Ethylene absorber.
Starter kit.
For placement in a fresh climate
drawer.
R A 430 100
Storage container with transparent
lid, anthracite.
R A 450 012
Activated charcoal water filter.
For RVY, RB and RF.
RV A 438 040
Solid oak wood bottle support with
magnetic connector.
RV A 450 220
Activated charcoal air filter.
Highlights
— Dark brushed stainless steel
interior, refined with solid
anthracite aluminium elements.
— Warm white and glare-free LED
light concept for optimal food
presentation in all compartments.
— Opening assist for door enabling
seamless integration without
handles.
— Flat dark brushed stainless steel
inner door.
— Flexible positioning of shelves and
door racks through hidden rail
system.
— Solid anthracite aluminium door racks.
— Professional freshness system with
2 fresh climate drawers and
1 chilled drawer.
— Integrated ice maker with fixed
water connection.
— Spacious, fully extendable freezer
compartment including
2 additional interior drawers.
— Full touch TFT display.
— Total volume: 576 litres.
Handling
Opening assist for door.
Cushioned door closing system.
Light and display response to drawer
interaction.
Automatic brightness adjustment
based on ambient illumination.
Easy accessible full touch TFT display.
Clear text display.
Animated quick guides to assist
appliance maintenance.
Technical features
Dynamic cold air distribution.
Automatic defrosting with defrost
water evaporation.
Constant air purification by
2 activated charcoal air filters.
Rest mode certified by Star-K.
Open-door and malfunction alarm.
Selected digital services
(Home Connect)
Storage management with cameras.
Personalisation function for saving
custom programmes.
Remote control and monitoring.
Remote diagnostics.
Please read additional information on
Home Connect on page 409.
Cooling
Professional freshness system.
No-Frost technology with fast cooling.
Temperature adjustable from
+2 °C to +8 °C.
3 aluminium-framed safety glass
shelves, individually adjustable in height.
1 integrated safety glass shelf with
satin matte finish.
Optimal food presentation with warm
white and glare-free, hidden LED light
bars (3000 K).
Flexible positioning of door racks
through hidden rail system.
6 door racks, thereof 4 height
adjustable.
Total volume of all refrigerator
compartments: 379 litres.
Fresh climate drawer
2 fresh climate drawers with humidity
control.
Temperature adjustable from
-1 °C to +2 °C.
Ideal storage conditions for different
foods through dedicated programmes
(e.g. Fruit, Vegetables, Meat).
Individual adjustment of temperature
and humidity.
Extended food preservation with
ethylene absorber.
Indirect illumination, transparent front.
Fully extendable, with cushioned
closing system.
Chilled drawer
Temperature dependent on cooling
compartment (always 2K to 3K lower).
Indirect illumination, transparent front.
Fully extendable, with cushioned
closing system.
Freezing
No-frost technology with fast freezing
at -30 °C.
4-star freezer compartment.
Temperature adjustable from
-24 °C to -16 °C.
Freezer burn protection.
Oxidation protection.
Freezing capacity 13 kg/24 h.
Storage time after malfunction 10 h.
Spacious, fully extendable freezer
compartment with synchronously
running pull-out rails.
2 extendable interior drawers.
Warm-white, glare-free LED lighting
(3000 K) within freezer compartment.
Total volume of freezer compartment:
197 litres.
Ice maker
Integrated in the freezer compartment,
with fixed water connection (inlet).
Can be switched off.
Particle filter for water inlet,
integrated in ventilation grille area.
Saturation indicator for filter via full
touch TFT display.
Ice cube production approx. 3 kg/24 h.
Removable ice storage container with
approx. 3 kg capacity.
Integrated, easy accessible ice cube
scoop.
Consumption data
Energy efficiency class D at a range of
energy efficiency classes from A to G.
Energy consumption 275 kWh/year.
Noise level 39 dB (A) re 1 pW.
Planning notes
Flat hinge.
Door opening angle of 115°,
fixable at 90°.
Max. door panel weight:
Each door 64 kg.
Drawer 14 kg.
When rest mode is active, the
appliance can only be opened using a
handle.
Shut-off valve for water connection
must be planned next to the
appliance and always be accessible.
If the water pressure exceeds 0.8 MPa
(8 bar), connect pressure relief valve
between water tap and hose set.
Please read additional planning notes
on page 312–315.
Connection
Total connected load 0.200 kW.
Connecting cable 3.0 m, pluggable.
Water inlet.
Supply hose 2.8 m with 3/4”
connection.
Water pressure 2 to 8 bar.
Special accessories
(order as spare part):
Part No. 11057720
Extension for water inlet, 2 m with 3/4”
connection.
