Full surface induction cooktop
400 series
C X 492
C X 492 101
Black glass ceramic.
Frameless.
Width 90 cm.
Included in the price
1 wireless cooking sensor for
temperature regulation.
Special accessories
C A 060 300
Cooking sensor for temperature
regulation within pots.
G N 232 110
Teppan Yaki plate made of multi ply
material, GN 1/1.
For full surface induction cooktops.
Highlights
— One single big cooking surface.
— Free positioning of cookware.
— All sizes and formats of cookware
can be used.
— TFT touch display for an intuitive
control of all functions.
— Cooking sensor function for
temperature control in pots.
— Professional cooking functions.
— Max. power output for big
cookware of up to 5.5 kW.
— Frameless for flush mounting.
Cooking zones
One unique cooking surface of
3200 cm².
Up to 6 items of cookware can be
placed simultaneously on the cooktop.
Handling
Easy to use colour graphic TFT touch
display with use indications.
Electronic power control in 17 output
levels.
Features
Cooking sensor function.
Professional cooking function.
Dynamic cooking function.
Teppan Yaki function.
Booster function for pots.
Booster function for pans.
Keep warm function.
Individual pot detection.
Cooking timer for each cooking
position.
Stopwatch.
Short-term timer.
Information key with use indicators.
Power management.
Selected digital services
(Home Connect)
Cooktop-based ventilation control
(with suitable hood).
Remote monitoring.
Remote diagnostics.
Please read additional information on
Home Connect on page 409.
Safety
Main switch.
Residual heat indication.
Child lock.
Safety shut-off.
Pause function.
Planning notes
Operates with magnetic (induction)
iron pots and pans only. For an optimal
heat distribution, the use of sandwich
bottom cookware is recommended.
The wok pan WP 400 001 cannot be
used with this appliance.
Installation is possible in worktops
made of stone, synthetics or solid
wood. Heat resistance and watertight
sealing of the cut edges must be
observed. Concerning other materials
please consult the worktop
manufacturer.
The bearing capacity and stability, in
the case of thin worktops in
particular, must be supported using
suitable substructures. Take into
account the appliance weight and
additional loads.
The groove must be continuous and
even, so that uniform placing of the
appliance on the gasket is ensured.
Do not use discontinuous lining.
Appliance must be fixed from
underneath.
Joint width may vary due to
dimensional tolerances of the glass
ceramic cooktop and the worktop
cut-out.
Appliance weight: approx. 31 kg.
Please read the installation details
regarding air ducting on page 212.
Please read additional planning notes
on page 132–136.
Connection
Total connected load 7.4 kW.
Connecting cable 1.5 m without plug.
Power consumption standby/
display off 0.5 W.
Power consumption standby/
network 2.0 W.
Please check the user manual for how
to switch off the WiFi module.
Cooktops
174
