Vario flex induction cooktop
400 series
V I 492
V I 492 115
Stainless steel frame.
Width 90 cm.
Knobs need to be ordered separately.
Necessary Installation accessories
CK I 450 010
Stainless steel knobs 400 series
for VI 492.
Electronic control.
Set of 5 knobs.
CK I 450 000
Black knobs 400 series for VI 492.
Electronic control.
Set of 5 knobs.
Installation accessories
V A 420 004
Connection strip for combination with
other Vario appliances of the
400 series for flush mounting.
V A 420 010
Connection strip for combination with
other Vario appliances of the
400 series for surface mounting.
Special accessories
C A 051 301
Teppan Yaki plate made of multi ply
material.
For flex induction cooktop.
C A 052 300
Griddle plate in cast aluminum.
Non-stick.
For flex induction cooktop.
C A 050 300
Flex Pan set, 3 pcs.
Non-stick coating.
For flex induction cooktop.
C A 055 300
Flex Pan large.
Non-stick coating.
For flex induction cooktop.
W P 400 001
Wok pan made of multiple-layer
material.
With round bottom and handle,
ø 36 cm, 6 litres, height 10 cm.
W Z 400 000
Wok attachment for wok pan.
Only for Vario induction cooktops.
Highlights
— Flex function for combining the
rectangular cooking areas.
— Free positioning of cookware inside
combined cooking areas.
— Large cooking zone for pots up to
ø 32 cm.
— Ideal for the original wok pan with
round bottom, with wok ring.
— Solid stainless steel knob, also
selectable with black robust
finishing, for precise control and
personalisation.
— Precision crafted 3 mm stainless steel.
— For surface mounting with a visible
edge or for flush mounting.
— Can be combined perfectly with
other Vario appliances of the
400 series.
Cooking zones
2 flex induction cooking areas
23x19 cm (2200 W, with booster
3700 W), linked together 23x38 cm
(3300 W, with booster 3700 W).
2 flex induction cooking areas
23x19 cm (2200 W, with booster
3700 W), linked together 23x38 cm
(3300 W, with booster 3700 W).
1 induction cooking zone ø 21 cm
(2200 W, with booster 3700 W),
automatically switches to ø 26 cm
(2600 W, with booster 3700 W) and to
ø 32 cm (3300 W, with booster 3700 W).
Handling
Control knobs with illuminated ring,
cooking zone and output level
markings.
Electronic power control in 12 output
levels.
User friendly control with bicoloured
display (white / orange).
Features
Flex function for rectangular cooking
areas.
Frying sensor function.
Booster function.
Stopwatch.
Short-term timer.
Options menu.
Power management.
Selected digital services
(Home Connect)
Cooktop-based ventilation control
(with suitable hood).
Remote monitoring.
Remote diagnostics.
Please read additional information on
Home Connect on page 409.
Safety
Operation indicator.
Pot detection.
2-stage residual heat indication.
Safety shut-off.
Planning notes
Depending on the type of installation
(surface-mounted or flush-mounted),
the specific location of the cut-out
and the knob positions may vary.
The horizontal positioning of the
knobs may be aligned with the
specific cooking areas and zones.
The drawing “Installation of the
control knob” must be observed if the
panel is more than 23 mm thick (there
must be a recess at the rear).
If combining several Vario appliances
of the 400 series, select combinations
with or without appliance cover, and a
connection strip VA 420 must be
placed between the appliances.
Depending on the type of installation,
the corresponding connection strip
must be provided.
The bearing capacity and stability, in
the case of thinner worktops in
particular, must be supported using
suitable substructures. Take into
account the appliance weight and
additional loads.
Additional instructions for flush
mounting:
Installation is possible in worktops
made of stone, synthetics or solid
wood. Heat resistance and watertight
sealing of the cut edges must be
observed. Concerning other materials
please consult the worktop
manufacturer.
The groove must be continuous and
even, so that uniform placing of the
appliance on the gasket is ensured.
Do not use discontinuous lining.
The joint width may vary due to size
tolerances of the combinations and of
the worktop cut-out.
Please read additional planning notes
on page 132 and 134.
If installing several appliances in
individual cut-outs allow for a division
bar of minimum 50 mm between the
individual cut-outs.
Operates with magnetic (induction)
iron pots and pans only. For an optimal
heat distribution, the use of sandwich
bottom cookware is recommended.
Special accessories
(order as spare parts):
Part No. 17006018
Frying sensor pan, ø 20 cm
Part No. 17006184
Frying sensor pan, ø 24 cm
Part No. 17006185
Frying sensor pan, ø 28 cm
Part No. 17006019
Frying sensor pan, ø 32 cm
Appliance can be snapped into the
worktop from above.
Appliance weight: approx. 24 kg.
Please read the installation details
regarding air ducting on page 212.
Connection
Total connected load 11.1 kW.
Connecting cable 1.5 m without plug.
Connecting cables 0.3 m and 1 m for
control knobs.
Power consumption standby/
display off 0.5 W.
Power consumption standby/
network 1.9 W.
Please check the user manual for how
to switch off the WiFi module.
