- Track
Notes:
*
For complete code ordering information, please see pages 214-215.
** For other CCT options, please contact us.
Related Products
Body
Optic
Applications
LED sources
Finish
Driver
Accessories
Designed by Franco Mirenzi (Registered)
Polaris
N/A
Powder coat in black (10), Embossed matt black (65),
white (11), or Embossed matt white (54) colour.
Option for either white or black integrated thermoplastic
screen.
An innovative solution for high performance, uniform
illumination with optimal visual comfort. The miniature light
heads and optics in the fixture create a high definition,
glare-controlled, circular light emission.
Application areas: residential, hotels, restaurants, retail,
corridors.
Inclusive of integrated non-dimmable driver.
Dimming Options: DALI, Phase, CASAMBI.
220-240V 50/60Hz.
Lens plus thermoplastic screen.
UGR < 16.
Light source options: High Power LED.
CRI: 90 | CCT: 3000K, 4000K.
Other CRI, CCT and Tuneable White options available on
request.
Track mounted spotlight with light body in cast aluminum
inclusive of Integrated diamond faceted no-dazzle screen
in thermoplastic.
Available with 3 circuit universal track adapter or Dali track
adapter.
Luminaire body in cast aluminum with integrated diamond
faceted screen made from thermoplastic.
Versatile aiming angle tiltable vertically 0°-90° in two
directions and rotatable horizontally 350°.
Polaris
Recessed
Series
P.16-21
Polaris
Wallwasher
Series
P.22-25
Polaris
Surface
P.134
Polaris
Pendant
P.160
For the most updated product information, please go to our website.
01: Black light body with white integrated louvre. 17: White light body with black integrated louvre.
Polaris 30
Polaris 30
Polaris 30
Polaris 30
Track with 4 LEDs
Track with 8 LEDs
Track with 12 LEDs
184
65
46
111
184
65
46
217
159
65
46
324
163
106
106
137
90O
90O
Product
Code
Light Source Code*
>CRI
CCT**
LED
Power
Nominal
Lumen
Beam Angle
(BAº)
Driver
Options
Finish
Polaris 30
4 LEDs
6480
BO11 High Power LED
90
30 3000K
4x2W
760 lm
34 / 50
D0
No Dim
01
W/B
40 4000K
960 lm
DA
Dali Dim
10
Black
Polaris 30
8 LEDs
6481
8x2W
1520 lm
DP
Phase Dim
65
Matt Black
1920 lm
DC
CASAMBI
11
White
Polaris 30
12 LEDs
6482
12x2W
2280 lm
54
Matt White
2880 lm
17
B/W
-
6 4 8 0 B O 1 1
9 0
3 0
3 4 D 0 0 1
Code ordering example:
360O
90O90O
IP20
