- Track
Notes:
*
For complete code ordering information, please see pages 214-215.
** For other CCT options, please contact us.
For related accessories, please see pages 116-117.
For the most updated product information, please go to our website.
Related Products
Body
Optic
Applications
LED sources
Finish
Driver
Accessories
Track 40 I 66 I 100 I 130
Zero Compasso
Coloured filters, linear spread, honeycomb louvre,
anti-glare tube, wallwasher visor.
Check page 116 for details.
Powder coat in black (10), Embossed matt black (65),
white (11), or Embossed matt white (54).
A timeless, iconic, cylindrical spotlight design, incorporating
the most advanced lighting technology with a minimalist
aesthetic, to suit any interior lighting application.
Application areas: retail, museums, hospitality, residential,
offices, lobbies.
Inclusive of integrated non-dimmable driver.
Dimming Options: DALI, 0-10V (Zero compasso 100, 130),
On-board Dim, CASAMBI.
220-240V 50/60Hz.
Lens.
Beam Angle: Super narrow (7°) / Narrow / Medium / Wide.
Light Source Options: High Power LED, COB LED.
CRI: 90 | CCT: 3000K, 4000K.
Other CRI and CCT options available on request.
Track mounted spotlight, inclusive of integrated driver, with
lighthead in cast aluminum.
Available with 3 circuit universal track adapter or Dali track
adapter.
Designed for passive cooling.
Available in four different sizes. Versatile aiming angle
tiltable vertically 0°-90° and rotatable horizontally 350°.
Zero Compasso
360O
90O
IP20
Zero Compasso 40
Zero Compasso 66
Zero Compasso 100
Zero Compasso 130
Track
Track
Track
Track
Ø 42
108
162
73
35
Ø 66
144
162
108
36
174
162
Ø 100
118
56
223
162
Ø 130
149
74
Product
Code
Light Source Code*
>CRI
CCT**
LED
Power
Nominal
Lumen
Beam Angle
(BAº)
Driver
Options
Finish
Zero Compasso 40
Track
6571
BR21
High Power LED 90
30 3000K
4W
439 lm
07
D0
No Dim
10
Black
40 4000K
483 lm
DA
Dali Dim
65
Matt Black
BC31
COB LED
6W
705 lm
16 / 26 / 36
DC
CASAMBI
11
White
770 lm
DN
On-board Dimmer 54
Matt White
Zero Compasso 66
Track
6573
BR21
High Power LED
6W
574 lm
05
636 lm
BC31
COB LED
11W
1160 lm
11 / 16 / 32
1258 lm
Zero Compasso 100
Track
6575
BR21
High Power LED
18W
1947 lm
07
D0
No Dim
2153 lm
DA
Dali Dim
BC33
COB LED
21W
2569 lm
15 / 24 / 38
DC
CASAMBI
2703 lm
D1
0-10V Dim
Zero Compasso 130
Track
6577
BR21
High Power LED
27W
2920 lm
07
DN
On-board Dimmer
3230 lm
BC33
COB LED
33W
3598 lm
12 / 22 / 32
3800 lm
90O
-
6 5 7 1 B R 2 1
9 0
3 0
0 7 D 0 1 0
Code ordering example:
