Notes:
*
For complete code ordering information, please see pages 214-215.
** For other CCT options, please contact us.
For the most updated product information, please go to our website.
Related Products
Body
Optic
Applications
LED sources
Finish
Driver
Accessories
- Recessed
A soft but powerful downlight, pairing form with function
and delivering excellent visual comfort. The added
flexibility of an adjustable version in either shape, makes
this a popular luminaire for many interior applications.
Application areas: retail, hotels, restaurants, hospitals,
gyms.
Powder coat in black (10), Embossed matt black (65),
white (11), or Embossed matt white (54).
Coloured filters, linear spread, honeycomb louvre, snoot,
anti-glare cone, anti-glare hood.
Check page 45 for details.
Supplied with non-dimmable remote driver.
Dimming Options: 0-10V Dim, DALI, Phase, CASAMBI.
220-240V 50/60Hz.
Lens.
Beam Angle: Narrow / Medium / Wide / Wallwasher.
Light source options: COB LED. Retrofit.
CRI: 90 | CCT: 3000K, 4000K.
Other CRI and CCT options available on request.
Round or square-shaped mounting trim in cast aluminum
with springs for trim installation on a ceiling thickness of
max. 25mm or brackets for trimless installation on a ceiling
thickness 12.5-15mm.
Luminaire body in cast aluminum. Easy relamping tool-free
via removable lamp front ring by twist and lock action.
Adjustable version tiltable vertically 0°-25° and rotatable
horizontally 350°.
Colosseo
Recessed
P.28-31
Ovo
Recessed
P.72
Recessed Round & Square 76 I 100
Punto
Fixed
Adjustable
For related accessories, please see page 45.
Punto Fixed
IP20
Product
Code
Light Source Code*
>CRI
CCT
LED
Power
Nominal
Lumen
Beam Angle
(00º)
Driver
Options
Finish
Punto 76
Fixed Round
RN23
MC31 COB LED
90
30 3000K
6W
710 lm
16 / 26 / 36
D0
No Dim
10
Black
RN24
40 4000K
770 lm
DA
Dali Dim
65
Matt Black
DP
Phase Dim
11
White
Punto 76
Fixed Square
RN25
DC
CASAMBI
54
Matt White
RN26
D1
0-10V Dim
GU04
Retrofit
GU4-MR16
00
00
/
/
00
00
No Driver
Punto 76
Punto 76
Fixed Round Trim
Ø71
Fixed Square Trim
71
115
Ø 76
76
115
Punto 76
Punto 76
Fixed Round Trimless
Ø76
Fixed Square Trimless
76
115
Ø 76
76
115
-
R N 2 3 M C 3 1
9 0
3 0
1 6 D 0 1 0
Code ordering example:
