Symbols & Icons
CE Mark - Product complies with CE Standard.
CSA Mark - Product complies with USA & Canada Standard.
Other third party product approvals
Our products include electrical and electronic components that
carry other world wide Test House approvals such as those
shown:
CLASS I
Luminaires of insulation Class I - with earth connector.
CLASS II
Luminaires of insulation Class II - With safety isolation, this
means the tension conductions element are protected by
additional isolation.
The isolation of an earth wire it is not necessary and the
connection to it is not allowed.
CLASS III
Luminaires of isolation Class III - designed for operation of
protected low voltage supply (>42V).
Zoom
Passes the 850O glow wire test in accordance with IEC 695-2-1.
850°
Passes the 960O glow wire test in accordance with IEC 695-2-1.
960°
Dim2Warm
Tuneable White
CASAMBI
Recyclable
IP_ _ Degree of Ingress Protection
IP_ _
1st
Number
Protection Against
Dust and Solid Objects
2nd
Number
Protection Against
Moisture and Liquids
0
No-Protection
0
No-Protection
1
Protection against solid
objects >50 mm
1
Protection against
dripping water
2
Protection against solid
objects >12 mm
2
Protection against
dripping water tilted
> 15 deg
3
Protection against solid
objects >2.5 mm
3
Protection against
spraying water
> 30 deg
4
Protection against solid
objects >1 mm
4
Protection against
spraying water
5
Dust - protected
5
Protection against
water jet
6
Dust - tight
6
Protection against
waves
7
Protection against
the effects of
immersion
8
Protection against
submersion
How to order
-
T 9 6 3 B R 2 1
9 0
3 0
B S D A 5 4
Code ordering example:
7
Body colour
6
Dimming options
5
Beam angle
4
CCT-LED colour temperature
3
LED CRI
2
LED Souce code
1
Product code
1
2
3
4
5
6
7
LED CRI
CCT-LED Colour temperature
Dimming Options
Body Colour
80
CRI > 80
27
Warm White 2700K
D0
No dimming
10
Black (RAL 9004)
90
CRI > 90
30
Warm White 3000K
DA
Dali Dim
11
White (RAL 9003)
93
CRI > 93
35
Warm White 3500K
DC
CASAMBI
#17
Black (RAL 9004) / White (RAL 9003 (B&W)
97
CRI > 97
40
Neutral White 4000K
DN
On-board Dimmer
35
Gold
98
CRI > 98
TW
Tuneable White 2700K - 5700K
54
Embossed matt white (RAL 9016)
65
Embossed matt black (RAL 9017)
Notes:
#17: white light body with black integrated louvre. For
black body with white integrated louvre consult us.
Product
Code
LED Source
Code
LED
Power
Nominal
Lumen
Beam Angle
CRI>90
3000K
High
Efficacy
Zero 33
T963
BR21
4.5W
487 lm
BS (8-80°)
Dimming Options
DA
Dali Dim
D0
No Dim
DC CASAMBI
DN On-board Dimmer
CCT Options
27
2700K
30
3000K
35
3500K
40
4000K
1
Product code
T963
2
LED Module code
BR21
3
LED CRI
90
4
CCT-LED colour temperature
30
5
Beam angle
BS
6
Dimming options
DA
7
Body colour
54
1
2
5
3
4
4
6
7
Code System for Standard Products
Body Color
10 Black (RAL 9004)
65 Embossed matt black (RAL 9017)
11 White (RAL 9003)
54 Embossed matt white (RAL 9016)
#17 Black (RAL 9004) /
White (RAL 9003 (B&W)
35 Gold
10 - Black
65 - Embossed matt black
11 - White
54 - Embossed matt white
