Micro 48V Track System
62
63
Power Supply & Control Options
Universal DALI
Track
End
Feed
DALI Dimmable Fixture
(DA)
Power Supply
-
+
-
+
N
L
L
N
+
-
+
-
DA
DA
DA
DA
48V
Bluetooth wireless Control
Track
End
Feed
CASAMBI Dimmable Fixture
(DC)
Power Supply
-
+
-
+
N
L
L
N
48V
Fixed Output
Track
End
Feed
Power Supply
-
+
-
+
N
L
L
N
48V
Power Supply
220-240VAC input,
48VDC output 70w power supply for low voltage track
220-240VAC input,
48VDC output 150w power supply for low voltage track
Code
2G35
2G36
Drop Voltage Table
Power Supply
(W)
A Distance power supply/feed unit (2x1.5mm2)
5m
10m
20m
30m
B Track Length with Δv≤5.5% (m)
(m)
(m)
(m)
(m)
60
50
50
50
50
100
50
50
40
25
150
50
40
20
Not admitted
200
40
30
Not admitted
Not admitted
250
35
20
Not admitted
Not admitted
Information refers to a load equivalent to the power supplied and equally distributed on the relevant lenght in the table.
DV≤5.5%
Lighting fixture
Remote Power Supply
B
A
Track
End feed
48Vdc
