EVO 48V Track System
Vivo
Top Mounted
Ø 45
Ø 75
133
147
16
16
179
179
127
80
110
Ø 58
130
119
167
16
144
179
Dimming Options
D0
No Dim
DC CASAMBI
DA
Dali Dim
D1
0-10V Dim
CCT Options
27
2700K
30
3000K
35
3500K
40
4000K
Product
Code
LED Module
Code
LED
Power
Nominal
Lumen
Beam Angle
CRI>93
3000K
High
Efficacy
Vivo 45
96J1
E025
9W
1208 lm
18° / 28° / 36°
Vivo 58
96J2
E031
15W
1740 lm
14° / 24° / 36°
E026
14W
1932 lm
18° / 25° / 37°
Vivo 75
96J3
E029
18W
2305 lm
13° / 26° / 36°
CRI>98
3000K
High
Rendering
Vivo 45
96J1
E020
9W
901 lm
18° / 28° / 36°
Vivo 58
96J2
E027
15W
1458 lm
18° / 25° / 37°
Vivo 75
96J3
E006
18W
1765 lm
14° / 26° / 37°
Angle Adjustment:
350O
360O
+/- 90O
Joint 1
vertical tilt
+/- 90O
Joint 2
tilt 220O
220O
360O
350O
220O
90O
IP20
Vivo Top Mount is designed for H-shaped pendant profiles and is available in 48V EVO track applications.
Vivo Series focuses on eco-friendly design and modularity. TicTok’s tool-free, and interchangeable LED
module facilitate design flexibility and ease of on-site maintenance. The tool-free interchangeable LED
module is available in Ø45, Ø58 and Ø75mm head sizes, the extended arm of the top mount design
provides extra vertical tiltable and rotation angles: an eco-friendly onsite maintainable solution.
LED Sources:
High Efficacy:
CRI: 93 | CCT: 2700K, 3000K, 3500K, 4000K
High Rendering:
CRI: 98 | CCT: 2700K, 3000K, 3500K, 4000K
Accessories:
• Wide & Dense Texture Honeycomb Louvre
• Elliptical Beam Diffuser
• Coloured Glasses Diffuser
• Opal Lens
• Spread Lens
• Cross blade Louvre
• Barn doors
• Wallwasher Cone 45°
Please see page 60 for details.
Vivo Top Mounted
10 - Black
65 - Embossed matt black
11 - White
54 - Embossed matt white
45 I 58 I 75
EVO 48V Track
