260
mm: Dimensioni in millimetri / Dimensions in Millimiters / Maße in Millimetern
DRIVER: 24V → p. 267
BOBINA 8mm - 6W/m
24V - 30W (5m x 6W/m)
Bobina LED adesiva sezionabile
Si consiglia l’applicazione su materiali ad alta conduzione termica (es.alluminio).
Cuttable adhesive LED Reel
Recommended application on high heat conductivity (ex.aluminium).
Selbsklebendes LED-Band
Kuerzbar; Anwendung mit waermeleitfaehigen Werkstoffen (z.B. Aluminium)
wird empfohlen.
110°
Ø 1000
Ø 2100
Ø 3150
Ø 4250
2700K
3000K
4000K
LUX
500mm
LED 24V-6W/m ERP
BOBINA / REEL
1515
510
275
160
1435
490
250
145
1425
495
250
145
168 - 171 - 194 lm/W | CRI≥80
Immagine / Image / Bild: 4000K
Bobina LED adesiva sezionabile
Si consiglia l’applicazione su materiali ad alta conduzione termica (es.alluminio).
Cuttable adhesive LED Reel
Recommended application on high heat conductivity (ex.aluminium).
Selbsklebendes LED-Band
Kuerzbar; Anwendung mit waermeleitfaehigen Werkstoffen (z.B. Aluminium)
wird empfohlen.
110°
Ø 1000
Ø 2100
Ø 3150
Ø 4250
2700K
3000K
4000K
LUX
500mm
1935
670
330
195
1925
650
330
190
1985
680
330
190
LED 24V-8W/m ERP
BOBINA / REEL
172 - 172 - 176 lm/W | CRI≥80
Immagine / Image / Bild: 4000K
BOBINA 8mm - 8W/m
24V - 40W (5m x 8W/m)
20
4 LED
0,16W
+DC24V 6L68084001 DC24V+
+DC24V 6L68084001 DC24V+
+DC24V 6L68084001 DC24V+
+DC24V 6L68084001 DC24V+
8084001 DC24V+
4,5
1.5
8
2000
10000
6CA1202045
6LC00009
LUMEN
K
V IN
L (mm)
LED N°
Watt
1L68082705
1L68083005
1L68084005
6900 lm
6900 lm
7070 lm
2700K
3000K
4000K
24V
5000
1000
40,00W
COD.
20
4 LED
0,12W
+DC24V 6L68064001 DC24V+
+DC24V 6L68064001 DC24V+
+DC24V 6L68064001 DC24V+
+DC24V 6L68064001 DC24V+
8064001 DC24V+
4,5
1.5
8
2000
10000
6CA1202045
6LC00009
LUMEN
K
V IN
L (mm)
LED N°
Watt
1L68062705
1L68063005
1L68064005
5040 lm
5150 lm
5820 lm
2700K
3000K
4000K
24V
5000
1000
30,00W
COD.
ACCESSORI
Accessories / Zubehör
EEC
EEC
Ø8
Ø8
