T E C H N I C A L I N F O
T E C H N I C A L I N F O
5 8 1
5 8 0
p. 456
p. 456
p. 469
p. 469
p. 469
p. 512
p. 496
p. 496
800 mm
90 mm
ø 70 mm
COORDINATES WALL 1
Finiture
Finishes
Colori
Colors
Michael Anastassiades, 2020
champagne anodizzato ·
anodized champagne
argent
F1810044
F1810033
DIMMABLE PARETE / WALL DIMMABLE
RF34169 (DALI)
Potenza · Power 15W
Tensione · Voltage 230V
led included
Fonte luminosa · Light source
LED module 15W 961lm 2700K CRI90
Materiali · Materials
alluminio estruso, silicone platinico opale estruso ·
extruded aluminum, platinic silicone extruded opal
Peso · Weight 0,8 Kg
400 mm
ø 70 mm
800 mm
COORDINATES WALL 2
Finiture
Finishes
Colori
Colors
Michael Anastassiades, 2020
champagne anodizzato ·
anodized champagne
argent
F1811044
F1811033
DIMMABLE PARETE / WALL DIMMABLE
RF34169 (DALI)
Potenza · Power 24W
Tensione · Voltage 230V
led included
Fonte luminosa · Light source
LED module 24W 1402lm 2700K
CRI90
Materiali · Materials
alluminio estruso, silicone platinico opale estruso ·
extruded aluminum, platinic silicone extruded opal
Peso · Weight 1 Kg
ø 73 mm
ø 45 mm
225 mm
FLAUTA H225 RIGA /INDOOR
Finiture
Finishes
Colori
Colors
Patricia Urquiola, 2020
nero·black
bianco · white
anodized copper
F2340030
F2340009
F2340015
Potenza · Power 12W
Tensione · Voltage 220-240V
led included
Fonte luminosa · Light source
2 LED 12W 493lm 2700K CRI95
Materiali · Materials
alluminio · aluminum
Peso · Weight 0,8 Kg
DIMMER INCLUDED
PUSH/DALI
ø 73 mm
ø 45 mm
500 mm
FLAUTA H500 RIGA /INDOOR
Finiture
Finishes
Colori
Colors
Patricia Urquiola, 2020
nero·black
bianco · white
anodized copper
F2342030
F2342009
F2342015
Potenza · Power 12W
Tensione · Voltage 220-240V
led included
Fonte luminosa · Light source
2 LED 12W 493lm 2700K CRI95
Materiali · Materials
alluminio · aluminum
Peso · Weight 1,5 Kg
DIMMER INCLUDED
PUSH/DALI
5 8 1
ø 73 mm
ø 45 mm
1000 mm
FLAUTA H1000 RIGA /INDOOR
Finiture
Finishes
Colori
Colors
Patricia Urquiola, 2020
nero·black
bianco · white
anodized copper
F2344030
F2344009
F2344015
Potenza · Power 12W
Tensione · Voltage 220-240V
led included
Fonte luminosa · Light source
2 LED 12W 493lm 2700K CRI95
Materiali · Materials
alluminio · aluminum
Peso · Weight 2,7 Kg
DIMMER INCLUDED
PUSH/DALI
370 mm
97 mm
210 mm
FOGLIO
Finiture
Finishes
Colori
Colors
Tobia Scarpa, 1966
bianco · white
nero · black
cromo · chrome
black nikel
oro 22K · gold 22K
F2400009
F2400030
F2400057
F2400063
F2400044
Potenza · Power 2 x MAX 100W
Tensione · Voltage 220-250V
Fonte luminosa · Light source
LED 11,5W E27 1100lm
[esclusa - excluded]
Materiali · Materials
acciaio · steel
Peso · Weight 3,63 Kg
ø 112 mm
85 mm
ø 60 mm
GLO-BALL WALL MINI
Finiture
Finishes
Colori
Colors
Jasper Morrison, 2002
bianco · white
bianco · white
F4190009 MIRROR
F4194009 C/W
Potenza · Power MAX 25W
Tensione · Voltage 220-250V
Fonte luminosa · Light source
LED 3,2W G9 400lm o · or
LED 2W G9 240lm
[esclusa - excluded]
Materiali · Materials
vetro · glass
Peso · Weight 0,29 Kg
C/W
MIRROR MOUNTING
ø 75 mm
ø 190 mm
160 mm
GLO-BALL C/ W ZERO
Finiture
Finishes
Colori
Colors
Jasper Morrison, 2009
bianco · white
F3335009
Potenza · Power MAX 60W
Tensione · Voltage 220-250V
Fonte luminosa · Light source
LED 8W E14 900lm o · or
LED 9W E14 900lm
[esclusa - excluded]
Materiali · Materials
vetro · glass
Peso · Weight 1 Kg
