T E C H N I C A L I N F O
T E C H N I C A L I N F O
5 5 9
5 5 8
p. 349
p. 349
p. 349
p. 349
p. 410
p. 424
p. 424
p. 424
782 mm
782 mm
COORDINATES S3
Finiture
Finishes
Colori
Colors
Michael Anastassiades, 2020
champagne anodizzato ·
anodized champagne
argent
F1850044
F1850033
Potenza · Power 71W
Tensione · Voltage 100 - 240V
led included
Fonte luminosa · Light source
STRIP LED 71W 3850lm 2700K CRI95
Materiali · Materials
alluminio estruso, silicone platinico opale estruso ·
extruded aluminum, platinic silicone extruded opal
Peso · Weight 3,2 Kg
DIMMER INCLUDED
1-10/PUSH/DALI
782 mm
782 mm
COORDINATES S3 CL III
Finiture
Finishes
Colori
Colors
Michael Anastassiades, 2020
champagne anodizzato ·
anodized champagne
argent
F1846044
F1846033
ALIMENTATORE / POWER SUPPLY
RF29209
DIMMER LED / LED DIMMER
RF26994
Potenza · Power 64W
Tensione · Voltage 48V
led included
Fonte luminosa · Light source
STRIP LED 64W 3850lm 2700K
CRI95
Materiali · Materials
alluminio estruso, silicone platinico opale estruso ·
extruded aluminum, platinic silicone extruded opal
Peso · Weight 2,3 Kg
1762 mm
922 mm
COORDINATES S4
Finiture
Finishes
Colori
Colors
Michael Anastassiades, 2020
champagne anodizzato ·
anodized champagne
argent
F1854044
F1854033
Potenza · Power 161W
Tensione · Voltage 100 - 240V
led included
Fonte luminosa · Light source
STRIP LED 161W 8830lm 2700K
CRI95
Materiali · Materials
alluminio estruso, silicone platinico opale estruso ·
extruded aluminum, platinic silicone extruded opal
Peso · Weight 7,9 Kg
DIMMER INCLUDED
1-10/PUSH/DALI
1762 mm
922 mm
COORDINATES S4 CLIII
Finiture
Finishes
Colori
Colors
Michael Anastassiades, 2020
champagne anodizzato ·
anodized champagne
argent
F1848044
F1848033
ALIMENTATORE / POWER SUPPLY
RF29209
DIMMER LED / LED DIMMER
RF26994
Potenza · Power 147W
Tensione · Voltage 48V
led included
Fonte luminosa · Light source
STRIP LED 147W 8830lm 2700K
CRI95
Materiali · Materials
alluminio estruso, silicone platinico opale estruso ·
extruded aluminum, platinic silicone extruded opal
Peso · Weight 5,2 Kg
ø 600 mm
730 mm
2700 mm
FRISBI
Finiture
Finishes
Colori
Colors
Achille Castiglioni, 1978
cromo · chrome
F2500000
Potenza · Power 1 x MAX 105W
Tensione · Voltage 220-250V
Fonte luminosa · Light source
LED 13W E27 1250lm
[esclusa - excluded]
Materiali · Materials
polimetilmetacrilato, acciaio ·
polymethylmethacrylate, steel
Peso · Weight 2,65 Kg
ø 112 mm
85 mm
2700 mm
MINI GLO-BALL S
Finiture
Finishes
Colori
Colors
Jasper Morrison, 1998
bianco · white
F4195009
Potenza · Power MAX 25W
Tensione · Voltage 220-250V
Fonte luminosa · Light source
LED 3,2W G9 400lm o · or
LED 2W G9 240lm
[esclusa - excluded]
Materiali · Materials
vetro · glass
Peso · Weight 0,67 Kg
ø 330 mm
270 mm
2700 mm
GLO-BALL S1
Finiture
Finishes
Colori
Colors
Jasper Morrison, 1998
bianco · white
F3005061
Potenza · Power MAX 150W
Tensione · Voltage 220-250V
Fonte luminosa · Light source
LED 15W E27 2700lm
[esclusa - excluded] ]
Materiali · Materials
vetro · glass
Peso · Weight 2,55 Kg
ø 450 mm
360 mm
2700 mm
GLO-BALL S2
Finiture
Finishes
Colori
Colors
Jasper Morrison, 1998
bianco · white
F3010061
Potenza · Power MAX 150W
Tensione · Voltage 220-250V
Fonte luminosa · Light source
LED 15W E27 2000lm o · or
LED 18W E27 2000lm o · or
LED 18W E27 1900lm
[esclusa - excluded]
Materiali · Materials
vetro · glass
Peso · Weight 3,77 Kg
