T E C H N I C A L I N F O
T E C H N I C A L I N F O
5 5 5
5 5 4
p. 372
p. 372
p. 372
p. 372
p. 372
p. 372
p. 372
p. 286
688 mm
510 mm
ARRANGEMENTS - SQUARE LARGE
Finiture
Finishes
Colori
Colors
Michael Anastassiades, 2018
nero opaco · matte black
F0409030
Potenza · Power 34W
Tensione · Voltage 48V
led included
Fonte luminosa · Light source
FLEX STRIP LED 34W 1657lm 2700K
CRI90
Materiali · Materials
alluminio · aluminum
Rosone escluso
Ceiling rose excluded
Peso · Weight 0,67 Kg
Ø 398 mm
ARRANGEMENTS - ROUND SMALL
Finiture
Finishes
Colori
Colors
Michael Anastassiades, 2018
nero opaco · matte black
F0406030
Potenza · Power 21W
Tensione · Voltage 48V
led included
Fonte luminosa · Light source
FLEX STRIP LED 21W 1068lm 2700K
CRI90
Materiali · Materials
alluminio · aluminum
Rosone escluso
Ceiling rose excluded
Peso · Weight 0,41 Kg
Ø 665mm
ARRANGEMENTS - ROUND MEDIUM
Finiture
Finishes
Colori
Colors
Michael Anastassiades, 2018
nero opaco · matte black
F0407030
Potenza · Power 35W
Tensione · Voltage 48V
led included
Fonte luminosa · Light source
FLEX STRIP LED 35W 1770lm 2700K
CRI90
Materiali · Materials
alluminio · aluminum
Rosone escluso
Ceiling rose excluded
Peso · Weight 0,75 Kg
Ø 1020 mm
ARRANGEMENTS - ROUND LARGE
Finiture
Finishes
Colori
Colors
Michael Anastassiades, 2018
nero opaco · matte black
F0408030
Potenza · Power 54W
Tensione · Voltage 48V
led included
Fonte luminosa · Light source
FLEX STRIP LED 54W 2751lm 2700K
CRI90
Materiali · Materials
alluminio · aluminum
Rosone escluso
Ceiling rose excluded
Peso · Weight 1,2 Kg
ø 150 mm
70 mm
2400 mm
ARRANGEMENTS SMALL ROSE
ACCESSORI · ACCESSORIES
Finiture
Finishes
Colori
Colors
nero · black
F0416030
Tensione · Voltage 120-270V
Descrizione · Description
Rosone dimmerabile piccolo da soffitto per
l’installazione di combinazioni fino a max 70W ·
Small dimmable ceiling rose for the installation of
combinations within max 70W
Peso · Weight 1,25 Kg
DIMMER INCLUDED
1-10/PUSH/DALI
ø 180 mm
90 mm
2400 mm
ARRANGEMENTS BIG ROSE
ACCESSORI · ACCESSORIES
Finiture
Finishes
Colori
Colors
nero · black
F0415030
Tensione · Voltage 100-240V
Descrizione · Description
Rosone dimmerabile grande da soffitto per
l’installazione di combinazioni fino a max 190W ·
Big dimmable ceiling rose for the installation of
combinations within max 190W
Peso · Weight 3,06 Kg
DIMMER INCLUDED
1-10/PUSH/DALI
ø 150 mm
8 mm
2400 mm
ARRANGEMENTS RECESSED ROSE
ACCESSORI · ACCESSORIES
Finiture
Finishes
Colori
Colors
nero · black
F0418030
Tensione · Voltage 100-240V
Descrizione · Description
Rosone da soffitto con alimentazione remota per
l’installazione di combinazioni fino a max 190W
· Ceiling rose with remote power supply for the
installation of combinations within max 190W
Peso · Weight 3,3 Kg
DIMMER INCLUDED
1-10/PUSH/DALI
252 mm
100 mm
ø 450 mm
ø 170 mm
ø 81 mm
BELLHOP GLASS S2
Finiture
Finishes
Colori
Colors
E. Barber & J. Osgerby, 2024
bianco · white
cioko
bright aluminum
F1081009
F1081026
F1081064
Potenza · Power 30W
Tensione · Voltage 220-240V
Fonte luminosa · Light source
LED 25W E27 3700lm
[esclusa - excluded]
Materiali · Materials
vetro, alluminio · glass, aluminum
Peso · Weight 7,5 Kg
