T E C H N I C A L I N F O
T E C H N I C A L I N F O
4 5 7
4 5 6
p. 263
p. 263
p. 263
p. 263
p. 368
p. 368
p. 107
p. 282
782 mm
782 mm
COORDINATES S3
Finiture
Finishes
Colori
Colors
Michael Anastassiades, 2020
champagne anodizzato ·
anodized champagne
argent
F1850044
F1850033
Potenza · Power 71W
Tensione · Voltage 120 - 277V
led included
Fonte luminosa · Light source
STRIP LED 71W 3850lm 2700K CRI95
[inclusa - included]
Materiali · Materials
alluminio estruso, silicone platinico opale estruso ·
extruded aluminum, platinic silicone extruded opal
Peso · Weight 3,2 Kg
DIMMER INCLUDED
1-10/PUSH/DALI
782 mm
782 mm
COORDINATES S3 CL III
Finiture
Finishes
Colori
Colors
Michael Anastassiades, 2020
champagne anodizzato ·
anodized champagne
argent
F1846044
F1846033
ALIMENTATORE / POWER SUPPLY
RF29209
DIMMER LED / LED DIMMER
RF26994
Potenza · Power 64W
Tensione · Voltage 48V
led included
Fonte luminosa · Light source
STRIP LED 64W 3850lm 2700K
CRI95 [inclusa - included]
Materiali · Materials
alluminio estruso, silicone platinico opale estruso ·
extruded aluminum, platinic silicone extruded opal
Peso · Weight 2,2 Kg
1762 mm
922 mm
COORDINATES S4
Finiture
Finishes
Colori
Colors
Michael Anastassiades, 2020
champagne anodizzato ·
anodized champagne
argent
F1854044
F1854033
Potenza · Power 161W
Tensione · Voltage 120 - 240V
led included
Fonte luminosa · Light source
STRIP LED 161W 8830lm 2700K
CRI95 [inclusa - included]
Materiali · Materials
alluminio estruso, silicone platinico opale estruso ·
extruded aluminum, platinic silicone extruded opal
Peso · Weight 7,9 Kg
DIMMER INCLUDED
1-10/PUSH/DALI
1762 mm
922 mm
COORDINATES S4 CLIII
Finiture
Finishes
Colori
Colors
Michael Anastassiades, 2020
champagne anodizzato ·
anodized champagne
argent
F1848044
F1848033
ALIMENTATORE / POWER SUPPLY
RF29209
DIMMER LED / LED DIMMER
RF26994
Potenza · Power 161W
Tensione · Voltage 48V
led included
Fonte luminosa · Light source
STRIP LED 161W 8830lm 2700K
CRI95 [inclusa - included]
Materiali · Materials
alluminio estruso, silicone platinico opale estruso ·
extruded aluminum, platinic silicone extruded opal
Peso · Weight 5,1 Kg
800 mm
90 mm
ø 70 mm
COORDINATES WALL 1
Finiture
Finishes
Colori
Colors
Michael Anastassiades, 2020
champagne anodizzato ·
anodized champagne
argent
F1810044
F1810033
Potenza · Power 15W
Tensione · Voltage 230V
led included
Fonte luminosa · Light source
LED module 15W 962lm 2700K
CRI90 [inclusa - included]
Materiali · Materials
alluminio estruso, silicone platinico opale estruso ·
extruded aluminum, platinic silicone extruded opal
Peso · Weight 0,80 Kg
400 mm
ø 70 mm
800 mm
COORDINATES WALL 2
Finiture
Finishes
Colori
Colors
Michael Anastassiades, 2020
champagne anodizzato ·
anodized champagne
argent
F1811044
F1811033
Potenza · Power 24W
Tensione · Voltage 230V
led included
Fonte luminosa · Light source
LED module 24W 1403lm 2700K
CRI90 [inclusa - included]
Materiali · Materials
alluminio estruso, silicone platinico opale estruso ·
extruded aluminum, platinic silicone extruded opal
Peso · Weight 1 Kg
ø 300 mm
298,5 mm
ø 98 mm
COPYCAT
Finiture
Finishes
Colori
Colors
Michael Anastassiades, 2015
oro 24K · 24K gold
rame · copper
nero · black
alluminio · aluminum
F1952044
F1952015
F1952030
F1952050
Potenza · Power 16W
Tensione · Voltage 100-240V/24V
led included
Fonte luminosa · Light source
1 COB LED 16W 900lm total 2700K
CRI83 [inclusa - included] DIMMABLE
Materiali · Materials
alluminio, vetro soffiato · aluminum, blown glass
Peso · Weight 3,6 Kg
DIMMER INCLUDED
ø 390 mm
390 mm
ø 160 mm
560 mm
DIABOLO
Finiture
Finishes
Colori
Colors
Achille Castiglioni, 1998 - 2020
beaver brown
cherry red
bianco · white
F2121026
F2121035
F2121009
Potenza · Power max 70W - 21W LED
Tensione · Voltage 220-240V
Fonte luminosa · Light source
LED 21W E27 2452lm o · or
LED 21W E27 2200lm
[esclusa - excluded]
Materiali · Materials
alluminio · aluminum
Peso · Weight 2,9 Kg
