T E C H N I C A L I N F O
T E C H N I C A L I N F O
4 4 3
4 4 2
p. 290
p. 290
p. 290
p. 290
p. 290
p. 290
p. 290
p. 290
1706 mm
ARRANGEMENTS - LINE
Finiture
Finishes
Colori
Colors
Michael Anastassiades, 2018
nero opaco · matte black
F0401030
Potenza · Power 29W
Tensione · Voltage 48V
led included
Fonte luminosa · Light source
FLEX STRIP LED 29W 1480lm 2700K
CRI90 [inclusa - included]
Il modulo Line non può essere installato
singolarmente, ma necessita di una
combinazione con altri elementi della fa-
miglia - Line cannot be installed alone, it
must be combined with other elements
Materiali · Materials
alluminio · aluminum
Rosone escluso
Ceiling rose excluded
Peso · Weight 0,7 Kg
1020 mm
720 mm
502 mm
ARRANGEMENTS - BROKEN LINE
Finiture
Finishes
Colori
Colors
Michael Anastassiades, 2018
nero opaco · matte black
F0405030
Potenza · Power 24W
Tensione · Voltage 48V
led included
Fonte luminosa · Light source
FLEX STRIP LED 24W 1200lm 2700K
CRI90 [inclusa - included]
Materiali · Materials
alluminio · aluminum
Rosone escluso
Ceiling rose excluded
Peso · Weight 0,65 Kg
495 mm
697 mm
ARRANGEMENTS - DROP UP
Finiture
Finishes
Colori
Colors
Michael Anastassiades, 2018
nero opaco · matte black
F0414030
Potenza · Power 32W
Tensione · Voltage 48V
led included
Fonte luminosa · Light source
FLEX STRIP LED 32W 1530lm 2700K
CRI90 [inclusa - included]
Materiali · Materials
alluminio · aluminum
Rosone escluso
Ceiling rose excluded
Peso · Weight 0,5 Kg
495 mm
697 mm
ARRANGEMENTS - DROP DOWN
Finiture
Finishes
Colori
Colors
Michael Anastassiades, 2018
nero opaco · matte black
F0413030
Potenza · Power 30W
Tensione · Voltage 48V
led included
Fonte luminosa · Light source
FLEX STRIP LED 30W 1530lm 2700K
CRI90 [inclusa - included]
Materiali · Materials
alluminio · aluminum
Rosone escluso
Ceiling rose excluded
Peso · Weight 0,5 Kg
395 mm
302 mm
ARRANGEMENTS - SQUARE SMALL
Finiture
Finishes
Colori
Colors
Michael Anastassiades, 2018
nero opaco · matte black
F0410030
Potenza · Power 20W
Tensione · Voltage 48V
led included
Fonte luminosa · Light source
FLEX STRIP LED 20W 883lm 2700K
CRI90 [inclusa - included]
Materiali · Materials
alluminio · aluminum
Rosone escluso
Ceiling rose excluded
Peso · Weight 0,5 Kg
688 mm
510 mm
ARRANGEMENTS - SQUARE LARGE
Finiture
Finishes
Colori
Colors
Michael Anastassiades, 2018
nero opaco · matte black
F0409030
Potenza · Power 34W
Tensione · Voltage 48V
led included
Fonte luminosa · Light source
FLEX STRIP LED 34W 1657lm 2700K
CRI90 [inclusa - included]
Materiali · Materials
alluminio · aluminum
Rosone escluso
Ceiling rose excluded
Peso · Weight 0,7 Kg
Ø 398 mm
ARRANGEMENTS - ROUND SMALL
Finiture
Finishes
Colori
Colors
Michael Anastassiades, 2018
nero opaco · matte black
F0406030
Potenza · Power 21W
Tensione · Voltage 48V
led included
Fonte luminosa · Light source
FLEX STRIP LED 21W 1068lm 2700K
CRI90 [inclusa - included]
Materiali · Materials
alluminio · aluminum
Rosone escluso
Ceiling rose excluded
Peso · Weight 0,5 Kg
Ø 665mm
ARRANGEMENTS - ROUND MEDIUM
Finiture
Finishes
Colori
Colors
Michael Anastassiades, 2018
nero opaco · matte black
F0407030
Potenza · Power 35W
Tensione · Voltage 48V
led included
Fonte luminosa · Light source
FLEX STRIP LED 35W 1770lm 2700K
CRI90 [inclusa - included]
Materiali · Materials
alluminio · aluminum
Rosone escluso
Ceiling rose excluded
Peso · Weight 0,8 Kg
