T E C H N I C A L I N F O
T E C H N I C A L I N F O
4 4 1
4 4 0
p. 234
p. 234
p. 234
p. 234
p. 146
p. 192
p. 192
p. 419
* The primer rose can be painted after installation with normal water-based finishes (tempera, stucco, water-based paint) to guarantee flawless integration with the building.
* Il rosone primer può essere dipinto dopo l'installazione con normali finiture a base d'acqua (tempera, stucco, vernice a base d'acqua) per garantire un'integrazione perfetta con la costruzione.
1611,3 mm
759,5 mm
ALMENDRA S3 Y SHORT
Finiture
Finishes
Colori
Colors
Patricia Urquiola, 2022
off-white
nude
ocher
anthracite
bay blue metallized
lilac metallized
off-white
nude
ocher
anthracite
bay blue metallized
lilac metallized
ROSONE BIANCO / WHITE ROSE
F0436009
F0436026
F0436027
F0436033
F0436039
F0436042
ROSONE PRIMER / PRIMER ROSE*
F0398009
F0398026
F0398027
F0398033
F0398039
F0398042
Potenza · Power 45W
Tensione · Voltage 220/240V
led included
Fonte luminosa · Light source
LED 45W 4200lm 2700K CRI95
[inclusa - included]
Materiali · Materials
policarbonato sostenibile, alluminio · sustainable
polycarbonate, aluminum
Peso · Weight 9,83 Kg
1862,3 mm
770,9 mm
ALMENDRA S3 Y LONG
Finiture
Finishes
Colori
Colors
Patricia Urquiola, 2022
off-white
nude
ocher
anthracite
bay blue metallized
lilac metallized
off-white
nude
ocher
anthracite
bay blue metallized
lilac metallized
ROSONE BIANCO / WHITE ROSE
F0421009
F0421026
F0421027
F0421033
F0421039
F0421042
ROSONE PRIMER / PRIMER ROSE*
F0399009
F0399026
F0399027
F0399033
F0399039
F0399042
Potenza · Power 45W
Tensione · Voltage 220/240V
led included
Fonte luminosa · Light source
LED 45W 4200lm 2700K CRI95
[inclusa - included]
Materiali · Materials
policarbonato sostenibile, alluminio · sustainable
polycarbonate, aluminum
Peso · Weight 10,13 Kg
1152 mm
323,7 mm
ALMENDRA S2 ARCH SHORT
Finiture
Finishes
Colori
Colors
Patricia Urquiola, 2022
off-white
nude
ocher
anthracite
bay blue metallized
lilac metallized
off-white
nude
ocher
anthracite
bay blue metallized
lilac metallized
ROSONE BIANCO / WHITE ROSE
F0448009
F0448026
F0448027
F0448033
F0448039
F0448042
ROSONE PRIMER / PRIMER ROSE*
F0394009
F0394026
F0394027
F0394033
F0394039
F0394042
Potenza · Power 30W
Tensione · Voltage 220/240V
led included
Fonte luminosa · Light source
LED 30W 2800lm 2700K CRI95
[inclusa - included]
Materiali · Materials
policarbonato sostenibile, alluminio · sustainable
polycarbonate, aluminum
Peso · Weight 5,85 Kg
1305,9 mm
323,7 mm
ALMENDRA S2 ARCH LONG
Finiture
Finishes
Colori
Colors
Patricia Urquiola, 2022
off-white
nude
ocher
anthracite
bay blue metallized
lilac metallized
off-white
nude
ocher
anthracite
bay blue metallized
lilac metallized
ROSONE BIANCO / WHITE ROSE
F0444009
F0444026
F0444027
F0444033
F0444039
F0444042
RROSONE PRIMER / PRIMER ROSE*
F0395009
F0395026
F0395027
F0395033
F0395039
F0395042
Potenza · Power 30W
Tensione · Voltage 220/240V
led included
Fonte luminosa · Light source
LED 30W 2800lm 2700K CRI95
[inclusa - included]
Materiali · Materials
policarbonato sostenibile, alluminio · sustainable
polycarbonate, aluminum
Peso · Weight 6,45 Kg
ø 300 mm
600 mm
AOY
Finiture
Finishes
Colori
Colors
Achille Castiglioni, 1975
opale · opal
F0200071
Potenza · Power 1 x MAX 100W + 1 x MAX 70W
Tensione · Voltage 220-250V
Fonte luminosa · Light source
LED 11,5W E27 1100lm +
LED 7W E27 650lm
[esclusa - excluded]
Materiali · Materials
vetro · glass
Peso · Weight 12,1 Kg
SWITCH INCLUDED
2200/2150 mm
ø 320 mm
240 mm
2400 mm
550 mm
1510/1850 mm
ARCO
Finiture
Finishes
Colori
Colors
Achille and Pier Giacomo Castiglioni, 1962
acciaio · steel
F0300000
Potenza · Power MAX 100W
Tensione · Voltage 220-250V
Fonte luminosa · Light source
LED 11W E27 1060lm
[esclusa - excluded]
Materiali · Materials
marmo, acciaio inox, alluminio · marble,
stainless steel, aluminum
Peso · Weight 63,8 Kg
SWITCH INCLUDED
2200/2150 mm
ø 320 mm
240 mm
2400 mm
550 mm
1415/1770 mm
ARCO LED
Finiture
Finishes
Colori
Colors
Achille and Pier Giacomo Castiglioni, 1962
acciaio · steel
F0303000
Potenza · Power 28W
Tensione · Voltage 100-240V/48V
led included
Fonte luminosa · Light source
1 MULTICHIP LED 28W 1224lm
2700K CRI93 [inclusa - included]
DIMMABLE
Materiali · Materials
marmo, acciaio inox, alluminio · marble,
stainless steel, aluminum
Peso · Weight 63,8 Kg
DIMMER INCLUDED
800/1000 mm
200 mm
ARIETTE 1/2
Finiture
Finishes
Colori
Colors
Tobia Scarpa, 1973
tessuto · fabric
tessuto · fabric
F0400009 ARIETTE 1
F0500009 ARIETTE 2
Potenza · Power 4 x MAX 40W
Tensione · Voltage 220-250V
Fonte luminosa · Light source
LED 11,5W E27 1100lm
[esclusa - excluded]
Materiali · Materials
tessuto · fabric
Peso · Weight 0,8 Kg (1) - 1 Kg (2)
