L: 900 mm
L: 1200 mm
L: 1500 mm
LIGHT STRIPE
DIRECT LIGHT
LIGHT STRIPE
INDIRECT LIGHT
L: 900 / 1200 / 1500
L: 944 / 1244 / 1544
205
15
ø30
50
18
I N F R A - S T R U C T U R E — P R O F I L E S
06.5110.40
06.5110.14
06.5111.40
06.5111.14
06.5112.40
06.5112.14
06.5113.40
06.5113.14
H: 100 mm
H: 300 mm
H: 400 mm
H: 700 mm
H
ø50
46
196
7
Light Modules:
Spots
Light Shadow Spots
Suspension Panel
Suspension Glass
Multifunction Smart Device
A End Cap
C Straignt Elements
A
A
C
C
D
D
C
D
B / D
C
B / D
Blind Tube
A
B
B Mecahnical Rod / *Data Rod / *Electrical Feed Rod
Ø 140 mm · *Direct access to Driver
D Mecahnical Rod / *Data Rod / *Electrical Feed Rod
Ø 50 mm · *Remote access to Driver
E
E Light Tube Direct / Indirect
L1
L2
L2
1100 mm
1600 mm
L1
1055 mm
1555 mm
Tubo cieco.
Modulo meccanico (senza
illuminazione) per l'installazione nel
sistema Infra-Structure. Elementi
di fissaggio girevoli 0°-90°, con
connessione magnetica e blocco
di sicurezza meccanico, per
installazione trasversale tra due linee
di profilo.
Blind tube.
A mechanical module (without
lighting) to be installed in the system
infrastructure. Fixing components
that rotate 0°-90°, with a magnetic
connection and a mechanical safety
lock. To be installed transversely
between two profile lines.
D Asta meccanica rosone ø50 mm.
Regolabile 25mm per poter essere
adattato a soffitti irregolari.
D Mechanical rod rose ø50 mm.
Adjustable 25 mm, to adapt it to
irregular ceilings.
