TRIMLESS DOWNLIGHTS
120
NQW X X X 1
Beam angle 10°
Apertura di fascio 10°
1
White
Bianco
5
Black
Nero
8
CRI85
9
CRI93
2
2700K
4
3
3000K
4000K
2700K
3000K
4000K
CRI85
CRI93
890 lm
840 lm
1000 lm
930 lm
1040 lm
960 lm
NONE Q10
design: Roberto Mantovani
Code Construction - Costruzione del codice
IP44
Trimless downlight
10W · 250mA (Vf 36V)
CRI85 - CRI93 · 2-Step MacAdam
F001 - 10°
30
60
75
96
Accessories - Accessori
ZQC004 White - Bianco
ZQC004B Black - Nero
Plasterboard recessing frame
Flangia per cartongesso
140
49
80x80 mm
Drivers - Alimentatori 250mA
on/off
dimmable
AL1025 (1) IP20
AL4030 (1) IP20 0/1..10V
ALD425 (1) IP20 DALI 2 PUSH
AL4031 (1) IP20 DALI 2
AL4032 (1) IP20 IGBT-TRIAC
40 mm
55 mm
55 mm
36 mm
55 mm
NRW X X X 1
Beam angle 10°
Apertura di fascio 10°
1
White
Bianco
5
Black
Nero
8
CRI85
9
CRI93
2
2700K
4
3
3000K
4000K
2700K
3000K
4000K
CRI85
CRI93
890 lm
840 lm
1000 lm
930 lm
1040 lm
960 lm
NONE R10
design: Roberto Mantovani
Code Construction - Costruzione del codice
IP44
Trimless downlight
10W · 250mA (Vf 36V)
CRI85 - CRI93 · 2-Step MacAdam
F001 - 10°
30
60
59
95
140
38
70 mm
ZQC003 White - Bianco
ZQC003B Black - Nero
Plasterboard recessing frame
Flangia per cartongesso
Accessories - Accessori
Drivers - Alimentatori 250mA
on/off
dimmable
AL1025 (1) IP20
AL4030 (1) IP20 0/1..10V
ALD425 (1) IP20 DALI 2 PUSH
AL4031 (1) IP20 DALI 2
AL4032 (1) IP20 IGBT-TRIAC
40 mm
55 mm
55 mm
36 mm
55 mm
