TRIMLESS DOWNLIGHTS
112
Drivers - Alimentatori 350mA
on/off
dimmable
AL1034 (1) IP20
AL1035 (1) IP20
AL1037 (1..2) IP20 S.P.
AL4000 (1) IP20 PUSH 0/1..10V
ALD435 (1) IP20 DALI 2 PUSH
AL4051 (1) IP20 DALI 2
AL4053 (1) IP20 PUSH IGBT-TRIAC
30 mm
40 mm
55 mm
72 mm
72 mm
36 mm
56 mm
on/off
Drivers - Alimentatori 500mA
dimmable
AL1074 (1) IP20
AL1084 (1) IP20 S.P.
AL4010 (1) IP20 PUSH 0/1..10V
ALD450 (1) IP20 DALI 2 PUSH
AL4151 (1) IP20 DALI 2
AL4153 (1) IP20 PUSH IGBT-TRIAC
30 mm
55 mm
72 mm
72 mm
36 mm
56 mm
F022 - 18°
F023 - 40°
30
60
30
60
2700K
3000K
4200K
6000K
350mA
500mA
623 lm
896 lm
651 lm
931 lm
721 lm 1078 lm
798 lm 1155 lm
ZERO Q14
design: Roberto Mantovani
Code Construction - Costruzione del codice
Trimless downlight
7-14W · 350-500mA (Vf 20,3V) · Series wiring - Cablaggio in serie
CRI85 · 2-Step MacAdam
Accessories - Accessori
IP44
ZZ2 X X X
1
18°
2
40°
0
2700K
1
3000K
2
4200K
3
6000K
6
Blue
Blu
7
Green
Verde
8
Red
Rosso
1
White
Bianco
5
Black
Nero
109
75
ZQC004 White - Bianco
ZQC004B Black - Nero
Plasterboard recessing frame
Flangia per cartongesso
LZZ201
Low luminance louver
Filtro antiabbagliamento
The f lter must be ordered
together with the lighting f xture.
Il f ltro deve essere ordinato
congiuntamente all’apparecchio.
Note - Nota
140
49
80x80 mm
Drivers - Alimentatori 350mA
on/off
dimmable
AL1034 (1..11) IP20
AL1035 (1..11) IP20
AL1037 (1..16) IP20 S.P.
AL4000 (1..12) IP20 PUSH 0/1..10V
ALD435 (1..11) IP20 DALI 2 PUSH
AL4051 (2..14) IP20 DALI 2
AL4053 (1..14) IP20 PUSH IGBT-TRIAC
30 mm
40 mm
55 mm
72 mm
72 mm
36 mm
56 mm
Drivers - Alimentatori 500mA
on/off
dimmable
AL1074 (1..7) IP20
AL1077 (1..6) IP20
AL1084 (1..11) IP20 S.P.
AL4010 (1..12) IP20 PUSH 0/1..10V
ALD450 (1..7) IP20 DALI 2 PUSH
AL4151 (2..14) IP20 DALI 2
AL4153 (1..14) IP20 PUSH IGBT-TRIAC
30 mm
40 mm
55 mm
72 mm
72 mm
36 mm
56 mm
ZERO MOVE 2
design: Roberto Mantovani
Code Construction - Costruzione del codice
IP44
Trimless & adjustable downlight
1-2W · 350-500mA (Vf 2,9V) · Series wiring - Cablaggio in serie
CRI85 · 2-Step MacAdam
Accessories - Accessori
ZSM X X X
0
10°
1
25°
0
2700K
1
3000K
2
4200K
3
6000K
6
Blue
Blu
7
Green
Verde
8
Red
Rosso
1
White
Bianco
5
Black
Nero
2
60°
2700K
3000K
4200K
6000K
350mA
500mA
89 lm
128 lm
93 lm
133 lm
103 lm
154 lm
114 lm
165 lm
AL7022
24VDC/500mA constant
current converter
Convertitore 24VDC/500mA
corrente costante
ZQM001 White - Bianco
ZQM001B Black - Nero
Plasterboard recessing frame
Flangia per cartongesso
55 mm
95
20
45
40
+/- 25°
360°
F001 - 10°
F002 - 25°
F003 - 60°
30
60
30
60
30
60
