RECESSED OPTIC DOWNLIGHTS
92
Drivers - Alimentatori 250mA
on/off
dimmable
AL1025 (1) IP20
AL4030 (1) IP20 0/1..10V
ALD425 (1) IP20 DALI 2 PUSH
AL4031 (1) IP20 DALI 2
AL4032 (1) IP20 IGBT-TRIAC
40 mm
55 mm
55 mm
36 mm
55 mm
Each f xture needs 4 drivers.
Considerare 4 alimentatori per ogni apparecchio.
Note - Nota
IP40
208x57 mm
HP14 X X X X
1
White
Bianco
2
5
Grey
Grigio
Black
Nero
8
CRI85
9
CRI93
S
36°
M
46°
W
60°
2
2700K
4
3
3000K
4000K
F971 - 36°
F972 - 46°
F973 - 60°
30
60
30
60
30
60
2700K
3000K
4000K
CRI85
CRI93
4 x 890 lm
4 x 840 lm
4 x 1000 lm
4 x 930 lm
4 x 1040 lm
4 x 960 lm
HAP 140
design: Lapo Grassellini
Code Construction - Costruzione del codice
Recessed optic downlight
4x10W · 250mA (Vf 4x36V)
CRI85 - CRI93 · 2-Step MacAdam
SHP1401 (4pcs)
Milky screen - Schermo opale
L0H1X4B Black - Nero (4pcs)
Low luminance louver
Filtro antiabbagliamento
Accessories - Accessori
The screen must be ordered
together with the lighting f xture.
Lo schermo deve essere ordinato
congiuntamente all’apparecchio.
Note - Nota
215
103
65
The f nishing refers to the
outer ring of the luminaire only,
the inner part of the optical
compartment is always black.
La f nitura fa riferimento al solo
anello esterno dell’apparecchio,
la parte interna del vano ottico è
sempre di colore nero.
Note - Nota
Drivers - Alimentatori 350mA
on/off
dimmable
AL1034 (1..11) IP20
AL1035 (1..11) IP20
AL1037 (1..16) IP20 S.P.
AL4000 (1..12) IP20 PUSH 0/1..10V
ALD435 (1..11) IP20 DALI 2 PUSH
AL4051 (2..14) IP20 DALI 2
AL4053 (1..14) IP20 PUSH IGBT-TRIAC
30 mm
40 mm
55 mm
72 mm
72 mm
36 mm
56 mm
Drivers - Alimentatori 500mA
on/off
dimmable
AL1074 (1..7) IP20
AL1077 (1..6) IP20
AL1084 (1..11) IP20 S.P.
AL4010 (1..12) IP20 PUSH 0/1..10V
ALD450 (1..7) IP20 DALI 2 PUSH
AL4151 (2..14) IP20 DALI 2
AL4153 (1..14) IP20 PUSH IGBT-TRIAC
30 mm
40 mm
55 mm
72 mm
72 mm
36 mm
56 mm
2700K
3000K
4200K
6000K
350mA
500mA
89 lm
128 lm
93 lm
133 lm
103 lm
154 lm
114 lm
165 lm
JIMBO 2
design: Roberto Mantovani
Code Construction - Costruzione del codice
IP40
50 mm
Recessed optic downlight
1-2W · 350-500mA (Vf 2,9V) · Series wiring - Cablaggio in serie
CRI85 · 2-Step MacAdam · Adjustable optics - Ottica variabile 10°-55°
AL7022
24VDC/500mA constant
current converter
Convertitore 24VDC/500mA
corrente costante
Accessories - Accessori
0
2700K
1
3000K
2
4200K
3
6000K
6
Blue
Blu
7
Green
Verde
8
Red
Rosso
JBS X X
1
White
Bianco
2
5
Grey
Grigio
Black
Nero
57
60
