RECESSED OPTIC DOWNLIGHTS
72
Drivers - Alimentatori 350mA
on/off
dimmable
AL1034 (1) IP20
AL1035 (1) IP20
AL1037 (1..2) IP20 S.P.
AL4000 (1) IP20 PUSH 0/1..10V
ALD435 (1) IP20 DALI 2 PUSH
AL4051 (1) IP20 DALI 2
AL4053 (1) IP20 PUSH IGBT-TRIAC
30 mm
40 mm
55 mm
72 mm
72 mm
36 mm
56 mm
on/off
Drivers - Alimentatori 500mA
dimmable
AL1074 (1) IP20
AL1084 (1) IP20 S.P.
AL4010 (1) IP20 PUSH 0/1..10V
ALD450 (1) IP20 DALI 2 PUSH
AL4151 (1) IP20 DALI 2
AL4153 (1) IP20 PUSH IGBT-TRIAC
30 mm
55 mm
72 mm
72 mm
36 mm
56 mm
2700K
3000K
4200K
6000K
350mA
500mA
623 lm
896 lm
651 lm
931 lm
721 lm
1078 lm
798 lm
1155 lm
LBZ101
Low luminance louver
Filtro antiabbagliamento
The f lter must be ordered
together with the lighting f xture.
Il f ltro deve essere ordinato
congiuntamente all’apparecchio.
Note - Nota
BABA R14
design: Roberto Mantovani
Code Construction - Costruzione del codice
Recessed optic downlight
7-14W · 350-500mA (Vf 20,3V) · Series wiring - Cablaggio in serie
CRI85 · 2-Step MacAdam
Accessories - Accessori
F020 - 18°
F021 - 40°
30
60
30
60
70
115
IP44
60 mm
BZ1 X X X
1
18°
2
40°
0
2700K
1
3000K
2
4200K
3
6000K
6
Blue
Blu
7
Green
Verde
8
Red
Rosso
1
White
Bianco
5
2
Grey
Grigio
Black
Nero
100
54
BABA Q10
design: Jude Allen
IP44
50mm
Drivers - Alimentatori 500mA
on/off
dimmable
AL1074 (1) IP20
AL1077 (1) IP20
AL1084 (1..2) IP20 S.P.
AL4010 (1..2) IP20 PUSH 0/1..10V
ALD450 (1) IP20 DALI 2 PUSH
AL4151 (1..2) IP20 DALI 2
AL4153 (1..2) IP20 PUSH IGBT-TRIAC
30 mm
40 mm
55 mm
72 mm
72 mm
36 mm
56 mm
Code Construction - Costruzione del codice
Accessories - Accessori
SBAQ101
Milky screen - Schermo opale
LBAQ101
Low luminance louver
Filtro antiabbagliamento
Note - Nota
The flter and the
screen must be
ordered together
with the lighting
fxture - Il fltro e lo
schermo devono
essere ordinati
congiuntamente
all’apparecchio.
AL7022
24VDC/500mA constant
current converter
Convertitore 24VDC/500mA
corrente costante
1
White
Bianco
2
5
Grey
Grigio
Black
Nero
BAQ1 X X X X
S
36°
M
46°
8
CRI85
9
CRI93
1
2200K
2
2700K
3
4
3000K
4000K
Recessed optic downlight
10W · 500mA (Vf 18V) · Series wiring - Cablaggio in serie
CRI85 - CRI93 (2700K-3000K-4000K only) · 2-Step MacAdam
F456 - 36°
F457 - 46°
30
60
30
60
2200K
2700K
3000K
CRI85
CRI93
810 lm
890 lm
840 lm
1000 lm
930 lm
4000K
1040 lm
960 lm
