IP RATED PROJECTORS
428
44 mm
48 mm
72 mm
Drivers - Alimentatori 350mA
on/off
dimmable
AL1034 (1..3) IP20
AL1035 (1..3) IP20
AL1037 (1..5) IP20 S.P.
AL9011 (1..4) IP67
AL4000 (1..4) IP20 PUSH 0/1..10V
ALD435 (1..3) IP20 DALI 2 PUSH
AL4051 (1..4) IP20 DALI 2
AL4053 (1..4) IP20 PUSH IGBT-TRIAC
AL6035 (1..3) IP67 DALI 2
AL8035 (2..4) IP67 DALI 2
30 mm
40 mm
55 mm
44 mm
72 mm
36 mm
56 mm
44 mm
48 mm
72 mm
Drivers - Alimentatori 500mA
on/off
dimmable
AL1074 (1..2) IP20
AL1077 (1..2) IP20
AL1084 (1..3) IP20 S.P.
AL9051 (1..3) IP67
AL4010 (1..4) IP20 PUSH 0/1..10V
ALD450 (1..2) IP20 DALI 2 PUSH
AL4151 (1..4) IP20 DALI 2
AL4153 (1..4) IP20 PUSH IGBT-TRIAC
AL6050 (1..2) IP67 DALI 2
AL8050 (2..4) IP67 DALI 2
30 mm
40 mm
55 mm
44 mm
72 mm
36 mm
56 mm
2700K
3000K
4200K
6000K
350mA
500mA
267 lm
384 lm
279 lm
400 lm
309 lm
462 lm
342 lm
495 lm
0
2700K
1
3000K
2
4200K
3
6000K
6
Blue
Blu
7
Green
Verde
8
Red
Rosso
LUP2 X X X
1
White
Bianco
5
9
Black
Nero
COR-TEN
S
18°
F
40°
W
120°
OLU 6 POLE
design: Roberto Mantovani
Code Construction - Costruzione del codice
IP65
IP-rated projector for Pole system
3-6W · 350-500mA (Vf 8,7V) · Series wiring - Cablaggio in serie
CRI85 · 2-Step MacAdam
F005 - 18°
F006 - 40°
30
60
30
60
30
60
F035 - 120°
69
44
XNTC01V White - Bianco
XNTC05V Black - Nero
XNTC09V COR-TEN
Antiglare snoot
Snoot antiabbagliamento
Accessories - Accessori
Made-to-measure cable
available on request.
Cavo a misura disponibile
su richiesta.
Note - Nota
LLUP201
Low luminance louver
Filtro antiabbagliamento
The f lter must be ordered
together with the lighting f xture.
Il f ltro deve essere ordinato
congiuntamente all’apparecchio.
Note - Nota
429
LMHP101
Low luminance louver
Filtro antiabbagliamento
The f lter must be ordered
together with the lighting f xture.
Il f ltro deve essere ordinato
congiuntamente all’apparecchio.
Note - Nota
MAHALO POLE
design: Roberto Mantovani
Code Construction - Costruzione del codice
IP65
IP-rated projector for Pole system
7W · 24VDC · Parallel wiring - Cablaggio in parallelo
CRI85 - CRI93 (2700K-3000K-4000K only) · 2-Step MacAdam
Accessories - Accessori
F971 - 36°
F972 - 46°
F973 - 60°
30
60
30
60
30
60
F036 - 120°
30
60
XNTX201V White - Bianco
XNTX205V Black - Nero
XNTX209V COR-TEN
Antiglare snoot
Snoot antiabbagliamento
Made-to-measure cable
available on request.
Cavo a misura disponibile
su richiesta.
Note - Nota
74
59
Drivers - Alimentatori 24VDC
on/off
dimmable
AL2124 (1) IP20
AL2012 (1..3) IP20
AL2031 (1..10) IP20
AL2040 (1..21) IP20
AL9222 (1..5) IP67
AL9231 (1..10) IP67
AL9240 (1..21) IP67
AL5012 (1..3) IP20 DALI 2 PUSH 0/1..10V
AL5241 (1..14) IP20 DALI 2 PUSH
AL8012 (1..3) IP67 DALI 2
60 mm
28 mm
70 mm
80 mm
44 mm
85 mm
85 mm
45 mm
70 mm
44 mm
dimming module
AL7035 IP20 DALI 2 PUSH 0/1..10V
Note - Nota
Dimming module AL7035 to be used in combination
with a 24VDC power supply.
Modulo di dimmerazione AL7035 da utilizzare in
combinazione con un alimentatore 24VDC.
48 mm
2200K
2700K
3000K
CRI85
CRI93
570 lm
630 lm 590 lm
700 lm 650 lm
4000K
730 lm
670 lm
MHP1 X X X X
S
36°
M
W
X
46°
60°
120°
8
CRI85
9
CRI93
1
White
Bianco
5
9
Black
Nero
COR-TEN
2
1
2700K
2200K
3
3000K
4
4000K
