Wiring devices modules for square plates
(45x45 mm window) Proxima series
WALL-MOUNT DEVICES
Description
The Proxima wiring devices modules for square plates with 45x45 mm window
offer a combination of functionality and refined design, discreetly adapting to any
environment. These modules are designed for the connection of domestic appliances
with AC voltage up to 250 V~ and are equipped with shutter contact protection. They
are mounted on a round or square wall box, with screw terminals for cables with a
cross-section of up to 2.5 mm².
Main features
• Connection of domestic consumers with AC voltage up to 250 V ~
• Contact protection via shutter
• Mounting on round or square wall box
• Screw terminals for cable cross-sections up to 2.5 mm²
Type of wiring devices modules
Accessories
The following accessories are available for completion and must be ordered
separately:
• Square magnetic plate EK-PQA-P-...
• Modules and components of the wiring devices to choose from: EK-PWT-IT-B,
EK-PWA-RZ, EK-PWA-SN, EK-PWA-CF, EK-PWT-...
• Mounting Bracket EK-SMP-71-1
• Optional: Mounting accessory EK-SMP-Q-1 (check flush-box compatibility)
Order information
Code
Type
Code
Type
EK-PWA-CF
1M hole cover plug
EK-PWT-DE
Schuko socket
EK-PWT-IT-B
Bypass socket
EK-PWT-DE-S
Schuko socket with spring-loaded terminals
EK-PWA-RZ
230V buzzer
EK-PWT-FR
French socket
EK-PWA-SN
230V bell
EK-PWT-FR-S
French socket with spring-loaded terminals
EK-PWT-BG
Button puller
EK-PWT-UN
Multi-standard socket
EK-PWT-IL
Israeli socket
EK-PWT-UK
UK socket
EK-PWT-IT-U
UNEL socket
EK-PWI-MG
Magnetic circuit breaker
Documentation
For more information see the technical documentation,
download from www.ekinex.com
EK-PWT-FR
EK-PWT-IT-B
EK-PWA-CF
EK-PWA-RZ
EK-PWA-SN
EK-PWT-BG
EK-PWT-IT-U
EK-PWT-DE
EK-PWT-DE-S
EK-PWT-FR-S
EK-PWT-IL
EK-PWA-UN
EK-PWA-UK
