Double symbols
DM03 Arrow (empty/full)
DM011 Speed 2
DM07 Bullets
(empty/full)
NS00 No symbol
DM08 On/Off (I/O)
DM02 Arrow (empty)
DM010 Speed 1
DM04 Arrow (full)
DM012 Speed 3
DM05 On/Off
DM013 Triple bullets
(empty/full)
DM06 Bullets (empty)
DM01 Simple arrow
DM09 Plus / minus
DM014 Volume
DM018 Plus / minus
DM016 On/Off
DM015 Triple bullets (empty/full)
DM017 On/Off (I/O)
DM020 Arrow (empty)
DM019 Simple arrow
DM021 Volume
DM023 Arrow (empty/full)
DM022 Bullets (empty/full)
Customization with text
WALL-MOUNT DEVICES
Text added to
upper area only
(max 12 characters)
Text added to central
area only (1 or 2 lines,
max. 12 chars each)
Square rockers can be customized with text to be shown in the upper,
central or lower areas. Texts must be specified at order time.
Text added to
lower area only
(max. 12 characters)
Text added to both
upper and lower areas
(max. 12 chars each)
Abcdefghilmn
Abcdefghilmn
Abcdefghilmn
Abcdefghilmn
Abcdefghilmn
Horizontal rectangular rockers can be customized
by means of text in their central area.
Text added to central area only
(1 or 2 lines, max. 12 chars each)
Abcdefghilmn
Vertical rectangular rockers can be customized with text to be shown
in the upper, central or lower areas.
Text added to upper area
(max. 12 chars each)
Text added to central area
(1 or 2 lines, max. 12 chars each)
Abcdefghilmn
Abcdefghilmn
Text added to central area only
(max. 11 chars each) 20venti series only
Abcdefghil
Abcdefghilmn
Text added to lower area
(max. 12 chars each)
How to order a rocker
Rockers for pushbuttons
Proxima series
WALL-MOUNT DEVICES
Rockers for pushbuttons Proxima series.
The ordering code of a rocker is formed by a fixed part (EK-TTP-) plus a variable part
which represents modularity, material, colour and finishing.
METAL
Modularity
Colour
Finishing
Code
round
(1 rocker Ø 11 mm)
steel brushed
brushed
EK-TTP-1-SSB
quantum carbon
EK-TTP-1-SBV
brass
EK-TTP-1-LBC
dark chocolate
EK-TTP-1-GBH
antique brass
EK-TTP-1-GBO
bianco puro RAL 9016
EK-TTP-1-LAR
bianco caldo
EK-TTP-1-LAA
nero opaco RAL 9005
EK-TTP-1-LAE
beige luxor
EK-TTP-1-LBL
bronze corked
EK-TTP-1-GBD
old copper
EK-TTP-1-SOC
round
(2 rockers Ø 11 mm)
steel brushed
brushed
EK-TTP-2-SSB
quantum carbon
EK-TTP-2-SBV
brass
EK-TTP-2-LBC
dark chocolate
EK-TTP-2-GBH
antique brass
EK-TTP-2-GBO
bianco puro RAL 9016
EK-TTP-2-LAR
bianco caldo
EK-TTP-2-LAA
nero opaco RAL 9005
EK-TTP-2-LAE
beige luxor
EK-TTP-2-LBL
bronze corked
EK-TTP-2-GBD
old copper
EK-TTP-2-SOC
round
(4 rockers Ø 11 mm)
steel brushed
brushed
EK-TTP-4-SSB
quantum carbon
EK-TTP-4-SBV
brass
EK-TTP-4-LBC
dark chocolate
EK-TTP-4-GBH
antique brass
EK-TTP-4-GBO
bianco puro RAL 9016
EK-TTP-4-LAR
bianco caldo
EK-TTP-4-LAA
nero opaco RAL 9005
EK-TTP-4-LAE
beige luxor
EK-TTP-4-LBL
bronze corked
EK-TTP-4-GBD
old copper
EK-TTP-4-SOC
METAL HT
Modularity
Colour
Finishing
Code
round
(1 rocker Ø 11 mm)
chrome
chrome plated
EK-TTP-1-CRO
black metal
EK-TTP-1-CBM
champagne
EK-TTP-1-SHA
round
(2 rockers Ø 11 mm)
chrome
EK-TTP-2-CRO
black metal
EK-TTP-2-CBM
champagne
EK-TTP-2-SHA
round
(4 rockers Ø 11 mm)
chrome
EK-TTP-4-CRO
black metal
EK-TTP-4-CBM
champagne
EK-TTP-4-SHA
