Description
Square frame of Form version for finishing Ekinex® devices of FF and 71 series.
Available in several colours and materials.
Main features
• In plastic material or aluminium
• Snap-on mounting
Order
Base-codes (EK-FOQ) must be completed by adding extensions for material,
colour and finishing (3 characters).
Square frame Form version
WALL-MOUNT DEVICES
Dimensions [mm]
86
8
86
Rectangular frame Form version
WALL-MOUNT DEVICES
Order information
Code
Dimensions L x H x P [mm]
For use with
Package
EK-FOQ-...
86 x 86 x 8
devices of FF and 71 series
1 pcs.
Description
Rectangular frame of Form version for finishing Ekinex® devices of FF and 71 series.
Available in several colours and materials.
Main features
• In plastic material or aluminium
• Snap-on mounting
Order
Base-codes (EK-FOR) must be completed by adding extensions for material,
colour and finishing (3 characters).
Order information
Code
Dimensions L x H x P [mm]
For use with
Package
EK-FOR-...
126 x 86 x 8
devices of FF and 71 series
1 pcs.
Dimensions [mm]
126
86
8
Description
Building site protection in transparent thermoformed plastic material for Ekinex®
pushbuttons FF, 71, 20venti series. The use of the protection prevents soiling of the
devices caused by painting. The reliefs in correspondence with each rocker allow the
pushbutton to be operated even with the protection present.
Thermoformed protection
for Ekinex pushbuttons
WALL-MOUNT DEVICES
Dimensions [mm] - FF series
84
7.1
79.5
Dimensions [mm] - 71 Deep series
85
9.9
85
Dimensions [mm] - 71 Surface series
97
7.7
97
Dimensions [mm] - 20venti Deep series
85
9.9
85
Dimensions [mm] - 20venti Surface series
97
7.7
97
Order information
Code
For use with
Package
EK-PTC-5-FF
devices of FF series
5 pcs.
EK-PTC-5-20-DE
devices of 20venti Deep series
5 pcs.
EK-PTC-5-71-DE
devices of 71 Deep series
5 pcs.
EK-PTC-5-20-SU
devices of 20venti Surface series
5 pcs.
EK-PTC-5-71-SU
devices of 71 Surface series
5 pcs.
