Motion sensor
Description
Code
a) Motion sensor with metallic support
EK-SN2-TP-GA_
b) Cover with lens
c) Square plate Surface version*
EK-SQN-...
d) Square plate*
EK-PQN-...
e) Square plate Deep version*
EK-DQN-...
f) Adapter for Surface square plate
EK-TAS-Q-W or EK-TAS-Q-N
Description
Code
g) Adapter for square plate
EK-TAQE-1
h) Adapter for ‘NF and Deep square plate
EK-TAQE-1-NF
i) Square frame of Flank version
EK-FLQ-...
l) Square frame of Form version
EK-FOQ-...
m) Round flush-mounting box
not delivered by Ekinex®
n) Square flush-mounting box
not delivered by Ekinex®
*) 50 x 50 mm window
The Ekinex® range of motion and presence sensors allows you to automate the control of bus functions, such as light-
ing or room climate control. All versions contain a KNX communication module inside. The SG2 versions are suitable
for indoor ceiling mounting.
The EK-SN2-TP version is suitable for indoor wall mounting and must be completed with a square plate with 50 x 50 mm
window and a square frame Flank or Form version, available in numerous material, colour and finish variants. The sensor can
also be installed without a frame by separately ordering a square ‘NF, Deep or Surface adapter available with a side profile
in a choice of black or white (only ‘NF). The EK-DH4-TP version is suitable for wall or ceiling mounting in outdoor areas.
The motion sensors are connected to the signal bus cable; they are SELV (Safety Extra Low Voltage) powered devices
that offer a higher level of safety than conventional sensors. Configuration and commissioning of the devices is carried
out using ETS® software; the relevant application programme can be downloaded from www.ekinex.com.
Motion sensors complete with frames
Form, Flank or in the' ‘NF, Deep
and Surface versions for aesthetics
coordinated to the Ekinex® pushbuttons.
