Style Case
SALES KIT
Description
Style Case was thought to display the Ekinex® wall-mounting devices, appreciate the
feel of materials and colours, test the effect on different wall backgrounds. It has four
drawers for the different product lines (two of them is equipped with functioning devices)
containing demo-versions of wall-mounted devices. Style Case also includes an array of
pushbutton faceplates as a colour sampler; the front lid hosts a pouch for catalogues or
note sheets. The suede leather belt provides for a convenient carrying handle.
For further information: sales@ekinex.com
Order information
Code
Package
Weight
EK-SC4-02
1 pcs.
9,300 Kg
Style Box
SALES KIT
Description
Stylebox is a presentation box that contains one or more Ekinex devices declined
in different colours and finishes to evaluate the different colour and aesthetic
solutions available.
For further information: sales@ekinex.com
Order information
Code
Version
Package
Weight
EK-SB4-FF-DK
Style Box FF Form series
1 pcs.
0.500 Kg
EK-SB4-71-DEEP-DK
Style Box 71 Deep series
EK-SB4-71-SURF-DK
Style Box 71 Surface series
EK-SB4-SIGN-DEEP
Style Box Signum Deep
EK-SB4-SIGN-SURF
Style Box Signum Surface
EK-SB4-METAL-HT-DK
Style Box Metal HT
EK-SB4-PWS-IT
Style Box Power sockets/USB - Italian
EK-SB4-PWS-DE
Style Box Power sockets/USB - Schuko
EK-SB4-PWS-UK
Style Box Power sockets/USB - UK
EK-SB4-PWS-FR
Style Box Power sockets/USB - French
EK-SB4-20-SURF
Style Box serie 20venti
EK-SB4-20-DK
EK-SB4-4PAN
Style Box Delégo panel 4”
EK-SB4-5PAN
Style Box Delégo panel 5”
1.500 Kg
EK-SB4-DICO
Style Box Dico
2.300 Kg
Tech Case
SALES KIT
Description
Tech Case is an ideal solution to support KNX training (basic, advanced, hvac)
and product presentations. Tech Case is made of a shock-resistant housing and
is equipped with an integrated trolley system that makes it suitable for business
travels. Tech Case is delivered with connected Ekinex devices and pre-installed
application programmes.
For further information: sales@ekinex.com
Order information
Code
Version
Package
Weight
EK-TCB-TP
basic
1 pcs.
11.000 Kg
EK-TCA-TP
advanced
12.000 Kg
Lettering
SALES KIT
Description
Ekinex logo lettering made of 3 mm thick pre-cut forex, complete with installation
template with positioning using double-sided adhesive tape.
For further information: sales@ekinex.com
Order information
Code
Package
Dimension
EK-LET-180
1 pcs.
180 cm
EK-LET-105
105 cm
EK-LET-45
45 cm
Crowner
SALES KIT
Description
Ekinex table display with Forest or Wood print, complete with packaging box.
For further information: sales@ekinex.com
Order information
Code
Package
Weight
EK-CROW-FOR (Forest print)
1 pcs.
0.500 Kg
EK-CROW-WOO (Wood print)
Wall-mount device not included in delivery.
