Dico is an IP outdoor door phone based on the SIP standard, which is fully integrated with the Delégo
visualisation system and can operate completely autonomously within the customer’s home network. It is a
fully touch product, with no physical buttons, and thanks to integration with the Ekinex cloud and the Delégo
app, it is possible to receive video calls wherever you are (feature available in Q1 2024).
Many functions in one device; Dico is not just a simple video IP Door phone. It manages a multiple access control
system through facial recognition, virtual keypad, QR code reading, and NFC technology. The innovative touch
screen compared to market standards (physical pushbuttons) also allows for extremely high configuration
flexibility and can be wall-mounted or flush-mounted using the special cover with mounting box.
With the latest deep learning algorithm and dual camera motion detection technology, EK-5DP-VI can be used
for residential and commercial applications to realize intelligent access control.
Dico
IP DOOR PHONE
The Dico IP door phone is a secure and affordable
commercial-grade device for both intercom
and for access control.
Description
IP Door phone offering excellent intercom-type communication and flexible
access control methods such as facial recognition based on artificial intelligence
and controllable by the mobile app. It can be used in commercial and community
applications to implement smart, fast, secure and reliable access control by
integrating with various third-party devices such as attendance and visitor
management systems.
Technical data
• 5” IPS LCD touch screen display
• 1280 x 720 pixel resolution
• 2M pixel dual-lens camera, WDR
• Input/output relays: 1 / 1
• Ethernet port RJ45, 10/100Mbps adaptive
• Power Supply 802.3af Power-over-Ethernet
• 12 Vdc power supply (if not using PoE)
• Max. current consumption 380 mA
• Tamper (tamper) supported
Recommended cable length depending on section for installation with
12V - 1.5 A power supply:
• ≤ 30m for section 20 AWG
• ≤ 20m for section 22 AWG
• ≤ 15m for section 23 AWG
Recommended cable length depending on section for installation with
12V - 1.0 A power supply:
• ≤ 20m for section 20 AWG
• ≤ 10m for section 22 AWG
Environmental operating conditions:
Wall-mounted or recessed installation with optional box and frame EK-5IW-VI
available for purchase from Ekinex. EK-5RC-VI rain cover available upon request.
Functions / Features
• Protection IP65
• Relative humidity of the installation environment: 10~90% non-condensing
• Operating temperature: -20°C to +55°C
• Dimensions (WxHxD): 192 x 88 x 27,5 mm
• Weight (assembled product): 600 g
• Flexible authentication: mobile app, facial recognition, NFC, QR codes, PIN codes,
IC card (contactless smart card)
• 1 output relay for door opener
• Visible light facial recognition
• Dual cameras with anti-spoofing algorithm against photo and video forgery
• Storage of up to 20.000 images and 20.000 cards
• Facial recognition speed of less than 0,2 seconds/user
• Facial recognition accuracy rate of more than 99,7%
• Allows audio and video communication with an IP phone, Delégo App or Delégo Panel
• Multiple verification methods including: face, PIN, NFC, RFID cards and QR codes
• Configuration via web browser
• Touch screen user interface with simplified navigation
• Excellent voice intelligibility in any situation, even noisy ones
• Easy installation requiring only power, internet and door opener
• Space-saving 5” design perfect for narrow door frames
Dico
IP DOOR PHONE
Documentation
For more information see the technical documentation,
download from www.ekinex.com
Order information
Code
Use
Packaging
EK-5DP-VI
IP Door phone 5”
1 pcs.
EK-5IW-VI
Box and frame for flush mounting
EK-5RC-VI
Rain cover
Dimensions [mm]
22.0
23.8
88.0
192.0
61.2
13.4
13.4
110.5
